Compact Semiconductor Fan Heater CSL 028

Name: Compact Semiconductor Fan Heater CSL 028
Brand: all-electronics-online.com
SKU: 792951815
Availability: InStock
Rating: 4.4 (111 reviews)

Price:	Negotiable/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	CSL 028
Heating Capacity:	150-400W
IP:	IP20

Product Description

Specifications
These small heaters are designed to prevent condensation and to ensure a minimum operating temperature in small enclosures.
Fan heater prevents formation of condensation and provides an evenly distributed interior air temperature in enclosures with electric/electronic components. The heater is connected using the internal terminal connectors The small size of the CS/CSL 028 makes it ideal for use in enclosures where space is at a premium.
Technical Data

Heating element	PTC heating element
Surface temperature	150W/250W: max. 50°C (122°F), except upper protective grille 400W: max. 65°C (149°F), except upper protective grille at 20°C (68°F) ambient temperature
Axial fan, ball bearing	air flow, free flow: CS 028: 13.8m³/h CSL 028: 45m³/h (230VAC), 54m³/h (120VAC) service life 40,000h at 40°C (104°F)
Connection	2-pole clamp max. 2.5mm² (CSL 028 with strain relief), clamping screw torque 0.8Nm max.
Casing	plastic according to UL94-0, black
Mounting	clip for 35 mm DIN rail, EN 60715 or screw fixing (Ø 5.3mm)
Fitting position	vertical airflow (air outlet up)
Operating / Storage temperature	-45 to +70°C (-49 to +158°F)
Operating / Storage humidity	max. 90 % RH (non-condensing)
Protection type / Protection class	IP20 / II (double insulated)

Art. No. clip fixing	Art. No. screw fixing	Series	Operating voltage	Heating capacity1)	Inrush current max.	Pre-fuse T (time-delay)	Dimensions	Weight (approx.)
02800.0-00	02800.0-01	CS 028	230VAC, 50/60Hz	150W	12A	6.3A	75 x 65 x 90mm	0.3kg
02811.0-00	02811.0-01	CSL 028	230VAC, 50/60Hz	250W	9A	6.3A	90 x 85 x 111mm	0.5kg
02810.0-00	02810.0-01	CSL 028	230VAC, 50/60Hz	400W	15A	10A	90 x 85 x 111mm	0.5kg
02800.9-00	02800.9-01	CS 028	120VAC, 50/60Hz	150W	6A	6.3A	75 x 65 x 90mm	0.3kg
02811.9-00	02811.9-01	CSL 028	120VAC, 50/60Hz	250W	6A	6.3A	90 x 85 x 111mm	0.5kg
02810.9-00	02810.9-01	CSL 028	120VAC, 50/60Hz	400W	9A	6.3A	90 x 85 x 111mm	0.5kg

according to UL499, intended for the use within an enclosure in accordance with UL508A
