Constant Voltage 12V 10W Plastic Triac Dimmable LED Driver with Ce

Name: Constant Voltage 12V 10W Plastic Triac Dimmable LED Driver with Ce
Brand: all-electronics-online.com
SKU: 772628325
Availability: InStock
Rating: 5 (131 reviews)

Price:	US $ 6.1-6.5/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	SD-830E10
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Item:	12V 10W Dimmable LED Driver
Output Power:	10W
Output:	Constant Voltage
Input Voltage:	AC180-250V
IP Rating:	IP20 Non Waterproof
Use:	for Spot Light, Down Light, Panel Light
Size:	1154527 mm
Case:	Plastic
Dimmer:	Triac Dimmer
Efficiency:	80%
Usage:	Construction, Building
Circuit Structure:	PWM Controlled
Output Type:	Terminal
Driving Method:	Constant Voltage or Constant Current
Certification:	CE, EMC, SAA
Power Supply Voltage:	AC220-240V
Brand:	Neonpro

Product Description

Constant voltage 12V 10W plastic Triac Dimmable LED Driver with CE

1.Constant voltage output .
2.Production standard : EMC and PCF (PF ≥0.9).
3. Dimmable ,work steadily ,no blinking phenomenon .
4. non-waterproof .
5.Guarantee: 2 years .

2.Application of 0.83A 10w dimmable led driver :
LED Signage
LED Architectural Lighting
LED Industrial Lighting
LED Sports Lighting
LED Cobra Head Lighting

3.Specification of 0.83A 10w dimmable led driver :

Model no.	SD-830E10
Input voltage	180-250 VAC 50/60 Hz
Max. power	10W
Dimmer	TRIAC Dimmer
Output type	Constant Current or Constant Voltage
Efficiency	80%
Output	12V
Overload protection	105% hiccup mode, auto-recovery
Over voltage protection	120% rated output voltage
Withstand voltage	I/P~O/P:1.5kVAC, 1 minute
Operating temperature	-25~40 degree
Installation	Non Waterproof
IP rating	IP20
Certificates/standards	CE
Connection input/output	Terminal
Dimensions(LWH)	1154527 mm

FAQ :
1.Shipment:
Ocean or air transportation, international express
2.Normal lead time:
1 day for in stock and 10-15 days for out of stock product
3.Price term:
FOB, C&F, EXW
30% before production, 70% before shipment.
4.Supply ability:
50000 units/month
5.MOQ:
10 units(but sample can be 1)
6. Discounts :
We offer discount for big quantity
7.OEM and ODM service.

Hyrite Lighting Company, also known as NeonPro Co, has 20 years experience in the design, development and manufacturing of electronic power supplies, one of an extremely successful range of signage products including, over the last seven years, LED modules and driver units.

The senior management having recognized the ongoing success and further potential of our LED products and utilizing their experience and proven track record in innovative product design and manufacture has formed Hyrite Lighting Company solely dedicated to manufacturing products specifically for the LED signage and lighitng markets.

Our products are surrently being used in many countries under different technical standards in a variety of climate conditions.

Pls kindly check our main products below,

*IP67 Slim high efficiency constant voltage LED power supply (New)

*Traditional IP67 constant voltage waterproof LED power supply

*IP45 Rainproof constant voltage LED power supply.

*IP20 indoor type LED power supply.

*Constant Current LED Driver for LED lighting.

*Dimmable LED driver.

*LED module for Channel letter/light box.

Certificate: CE RoHS SASO SAA TUV UL approved

In addition we offer comprehensive OEM and ODM services to our partners.

We sincerely welcome your visiting and valued advices to us. Any questions from you, our experienced salesperson will feedback to you within 12 hours.
