Controller & Inverter All in One for Wind and Solar System

Name: Controller & Inverter All in One for Wind and Solar System
Brand: all-electronics-online.com
SKU: 827550675
Availability: InStock
Rating: 4.7 (128 reviews)

Price:	Negotiable/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Product Description

1.Technical Data

Product Model	FN-CI10-48AWMMT
Rated Wind Power	1000W
Rated Solar Power	1000W
Rated Output Power	1000W
Rated Battery Voltage	48VDC
No-load Loss Current	≤0.7A
Output Wave	Pure Sine Wave
Display Mode	LCD
Cooling	Fan
Rated Output Voltage	220 VAC
Wave Distortion	≤4%
Output Frequency	50±0.5Hz
Dynamic Response	5%
Power Factor	≥0.8
Over-load Capacity	120% 1 min; 150% 10s
Inverter Efficiency	Maximum 90%
Isolating Mode	Frequency Toroidal transformer
Noise (1 m)	≤40dB
Insulating Strength	1500VAC,1 min
Protection Function	Solar reverse charge protection , Solar reverse connection protection, Battery over voltage protection, Battery over discharge protection, Battery reverse connection protection, Output overload protection, Output short circuit protection, Overheating protection. Wind turbine automatic brake and manual brake.
Ambient Temperature	-20~+55°C
Working Altitude	≤4000m
Ambient Humidity	0~90%, without condensing
In order to serve our customers better. Our company can adjust parameters configuration according to customer's requirement.

Dongguan Fonergy Technology Limited Co., Ltd is a high-tech manufacturer focused on design,

Production and application of high performance and reliable small wind turbine products. Our factory was established in 2001 located in northern part of Guangzhou city, factory has 150 workers, and a 10 people R&D team dedicated in higher performance and reliability of HY wind turbine. We owns 35 patent designs on wind turbine blade, slip ring, rotor structure, over-speed control system etc. Each and every component of HY wind turbine is independently designed and manufactured in house. Our factory owns advanced wind turbine quality testing equipments and a strict quality control system, all products will go through 22 quality control processes all in our factory facility. All products has certifcated with CE, ETL, RoHS and ANAB.

With over 12 years experience in production and application of wind & solar hybrid power system,

Fonergy has developed over 20 different application felds of wind and wind solar hybrid system such as residential grid-tie power system, residential off-grid power system, stand-alone wind solar hybrid street lighting, wind solar hybrid powered telecom tower, wind solar hybrid powered monitoring system etc. Most of these applications have been widely applied around world and enjoyed a good reputation by its system quality, reliability and professional pre-sales and after-sales service of our team. Furthermore, Our engineering team could provide whole system design and full construction support base on your specific requirements. We believe soon you will benefit from our professionalism.
