copper flexible electrical cable 4 core 6 sqmm
| Price: |
US $ 0.1-1/Meter |
| Min Order: |
100/Meter |
| Pay Type: |
L/C,T/T,Western Union |
| Prod Model: |
H05VV |
| Colour: |
Customized |
| Standard: |
IEC60227 |
| Type: |
Insulated |
| Conductor Material: |
Copper |
| Insulation Material: |
PVC |
| Certification: |
CCC |
| Conductor Type: |
Flexible |
| Application: |
Building Wire |
| Range Of Application: |
Wiring |
| Brand: |
Ronda |
Product Description
Application:
Flexible cable for medium mechanical stresses. Permitted frequent bending and twisting. Specially suitable for application in household, kitchens and offices in dry and damp conditions, for inst. Washing-machines, dryers, refrigerators etc., as long as the cable is adapted to essential specifications of the device. Also suitable for cookers, i.e. hot devices, on condition that it does not get in direct contact with hot parts of the device and is not exposed to heat irradiation. Suitable for fixed installation in furniture, partition walls, decorative linings and cavities in prefabricated construction elements.
Construction:
Conductor: bare copper conductor, fine wired stranded, class 5 acc. To IEC 60228
Insulation: PVC compound acc. To IEC 60227
Sheath:PVC compound for flexible insulated conductors acc. To IEC60227
Sheath colors: white or black
Technical Data:
during installation: +5 °C up to+70 °C fixed installed: -30 °C up to+70 °C
at short circuit of max. 5 s: up to 150 °C ambient temperature at storage: up to 40 °C
Nominal voltage: Uο/U =300/500 V Test voltage: 2000V
Minimal inner bending radius: 4D for D < 8 mm; 5D for 8 - 12mm; 6D for D > 12 mm
| Dimensions - number of cores x conductor cross-section | Construction of individual conductor | External diameter | Insulation thickness | Sheath thickness | Conductor resistance at 20 °C | Specific. El. Resistance of insulation at 70°C | Cu
weight | Cable weight | Packing |
| | nominal | min-max. | nominal | nominal | max. | min. | | Appro. | |
| mm² | n x mm | mm | mm | mm | Ω/km | MΩkm | kg/km | kg/km | |
| 2 x 0,75 | 24 x 0,20 | 5,7 - 07,2 | 0,6 | 0,8 | 26,0 | 0,011 | 14,4 | 52 | c.100 |
| 2 x 1 | 32 x 0,20 | 5,9 - 07,5 | 0,6 | 0,8 | 19,5 | 0,010 | 19,2 | 65 | c.100 |
| 2 x 1,5 | 48 x 0,2 | 6,8 - 08,6 | 0,7 | 0,8 | 13,3 | 0,010 | 28,8 | 90 | c.100 |
| 2 x 2,5 | 49 x 0,25 | 8,4 - 10,6 | 0,8 | 1,0 | 7,98 | 0,0095 | 48,0 | 115 | c.100 |
| |
| 3G0,75 | 24 x 0,20 | 6,0 - 07,6 | 0,6 | 0,8 | 26,0 | 0,011 | 21,6 | 70 | c.100 |
| 3G1 | 32 x 0,20 | 6,3 - 08,0 | 0,6 | 0,8 | 19,5 | 0,010 | 28,8 | 80 | c.100 |
| 3G1,5 | 48 x 0,2 | 7,4 - 09,4 | 0,7 | 0,9 | 13,3 | 0,010 | 43,2 | 115 | c.100 |
| 3G2,5 | 49 x 0,25 | 9,2 - 11,4 | 0,8 | 1,1 | 7,98 | 0,0095 | 72,0 | 175 | c.100 |
| 3G4 | 56 x 0,30 | 10,5 - 13,1 | 0,8 | 1,2 | 4,95 | 0,0078 | 115,2 | 235 | CUT |
Page 8
| Dimensions - number of cores x conductor cross-section | Construction of individual conductor | External diameter | Insulation thickness | Sheath thickness | Conductor resistance at 20 °C | Specific. el. resistance of insulation at 70°C | Cu weight | Cable weight | Packing |
| 4G0,75 | 24 x 0,20 | 6,6 - 08,3 | 0,6 | 0,8 | 26,0 | 0,011 | 28,8 | 75 | c.100 |
| 4G1 | 32 x 0,20 | 7,1 - 09,0 | 0,6 | 0,9 | 19,5 | 0,010 | 38,4 | 92 | c.100 |
| 4G1,5 | 48 x 0,20 | 8,4 - 10,5 | 0,7 | 1,0 | 13,3 | 0,010 | 57,6 | 145 | c.100 |
| 4G2,5 | 49 x 0,25 | 10,1 - 12,5 | 0,8 | 1,1 | 7,98 | 0,0095 | 96,0 | 210 | c.100 |
| 4G4 | 56 x 0,30 | 11,5 - 14,3 | 0,8 | 1,2 | 4,95 | 0,0078 | 153,6 | 299 | CUT |
| 4G6 | 84 x 0,30 | 14,7 | - | - | 3,30 | 0,0068 | 230,4 | 480 | CUT |
| |
| 5G0,75 | 24 x 0,20 | 7,4 - 9,3 | 0,6 | 0,9 | 26,0 | 0,011 | 36,0 | 96 | c.100 |
| 5G1 | 32 x 0,20 | 7,8 - 9,8 | 0,6 | 0,9 | 19,5 | 0,010 | 48,0 | 113 | c.100 |
| 5G1,5 | 48 x 0,20 | 9,3 - 11,6 | 0,7 | 1,1 | 13,3 | 0,010 | 72,0 | 175 | c.100 |
| 5G2,5 | 49 x 0,25 | 11,2 - 13,9 | 0,8 | 1,2 | 7,98 | 0,0095 | 120,0 | 260 | c.100 |
| 5G4 | 56 x 0,30 | 13,0 - 16,1 | 0,8 | 1,4 | 4,95 | 0,0078 | 192,0 | 363 | CUT |
| 5G6 | 84 x 0,30 | 16,7 | - | - | 3,30 | 0,0068 | 288,0 | 583 | CUT |
| |
| 7G1 | 32 x 0,20 | 09,0 | 0,6 | - | 19,5 | 0,010 | 67,2 | 136 | c.100 |
| 7G1,5 | 48 x 0,20 | 10,6 | 0,7 | - | 13,3 | 0,010 | 100,8 | 195 | c.100 |
| 7G2,5 | 49 x 0,25 | 13,0 | 0,8 | - | 7,98 | 0,0095 | 168,0 | 294 | c.100 |
*) Packing: c.100 = coil 100 m
