Cross-Linked Heat Shrinkable Insulation Tape (Bus-bar tape)

Prod Model:	0875
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Width:	25,50,75,100mm
Length:	5000mm
Thickness:	0.8mm,1.0mm
Self Shrink Ratio:	>30%
Shrink Temperature:	100 Deg C
Withstand Temperature:	-55~105 Deg C
Adhesive:	Hot Melt Adhesive
Feature:	Insulation, Waterproof and Anti-Corrosion
Application:	Electrical Winding Insulation
Type:	Insulation Tape
Chemistry:	Hybrid Insulation
Maximum Voltage:	20KV~100KV
Brand:	Maxwel
Material:	Polyolefin
Color:	Black,Red,Yellow and Green

Product Description

Cross-linked Heat Shrinkable Insulation tape(Bus-bar tape)

Cross-linked Heat shrinkable insulation tape adopts Cross-linked polyolefin and environmental friendly heat melted adhesive that can be used for insulation, waterproof and anti-corrosion purposes.
Features:
1. Partial repair of the cable protective layers suffered by mechanical and heat damage and corrosions and breakages caused by organic solvent.
2. Waterproof treatment at the ends of protective sleeves of heat shrinkable power cable joints.
3. Anti-corrosion and seal of pipes.
4. Insulation of bus bars in switchgear board and power stations.
5. Withstand temperature: -55~105 centigrade degree.
6. Shrink temperature: 100 centigrade degree.
7. Self shrink ratio: >30%.
8. Colors: Black, red, yellow, etc

Dimensions


Model	Standard Width(mm)	Standard Thickness(mm)	Standard Package(m)
0825	25	0.8±0.1	5 or 10
0850	50	0.8±0.1	5 or 10
0875	75	0.8±0.1	5 or 10
08100	100	0.8±0.1	5 or 10
1025	25	1.0±0.1	5 or 10
1050	50	1.0±0.1	5 or 10
1075	75	1.0±0.1	5 or 10
10100	100	1.0±0.1	5 or 10
