| Prod Model: |
PROCEMAC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
Procemac Thermal CTP Plate Processor |
| Material: |
Thermal CTP Plate and Ctcp Plate |
| Capacity: |
12-90 M/Hr |
| Plate Width (Mm): |
900 |
| Min. Plate Length(Mm): |
300 |
| Plate Thickness(Mm): |
0.15-0.4 |
| Tank Content, Developer(L): |
45 |
| Tank Content, Wash(L): |
35 |
| Adjustable Temperature, Dev: |
0 to 40 Degree C. Adjustable |
| Adjustable Temperature, Dry: |
Normal Temperature to 70 Degree C. |
| Usage: |
Offset Printing |
| Plate: |
Lithography Printing |
| Type: |
CTP Plate Making Machine |
| Light Source: |
Semiconductor Laser |
Product Description
1. Exquisite Design and Enduring Duralumin Material
Built with highly acid-resistant duralumin materials and PVC tank inside, McLantis thermal CTP plate processor is designed with long operation life.
2. Precise Electronic Controls
Equipped with Precise Siemens PLC control, McLantis thermal CTP plate processor operates the develop-wash-gum-dry process smoothly without any letup.
3. Easy Operation and Maintenance
McLantis thermal CTP plate processor can be connected to most thermal CTP brands and operates online or offline. Suitable for most brands 0.15 mm - 0.4 mm thermal plates. Convenient access to all serviceable components.
4. Superior Plate Developing Performance
Developing processing roller assures no damage to the plate surface and two sets of brushes assures sufficient development to the plate in McLantis thermal CTP plate processor. Equipped with automatic anti-oxidation detecting and replenishing system, McLantis processors accurately control developer concentration.
5. Independent Cooling System
Independent cooling system on McLantis thermal CTP plate processor keeps the developing temperature fluctuation within 0.5 degree Celsius.
6. Environmental Friendly
Gumming process with automatic cleaning and recycling function. Energy saving and environmental friendly.
| Model | PROCEMAC thermal CTP plate processor |
| 90PT | 125PT | 150PT | 165PT |
| Material | thermal CTP plate and CTCP plate |
| Capacity | 12-90 m/hr |
| Plate width (mm) | 900 | 1250 | 1500 | 1650 |
| Min. Plate length(mm) | 300 | 400 | 400 | 400 |
| Plate thickness(mm) | 0.15-0.4 |
| Tank content, developer(L) | 45 | 60 | 75 | 100 |
| Tank content, wash(L) | 35 | 45 | 60 | 80 |
| Adjustable temperature, dev | 0 to 40 degree C. adjustable |
| Adjustable temperature, dry | normal temperature to 70 degree C. |
| Water consumption, max | 8 L/min | 12 L/min | 15 L/min | 20 L/min |
| Diameter of wash brush (mm) | 50 |
| Rotary speed of wash brush | 80 rpm |
| Filter(um) | 75 |
| Water supply | tap water (min. pressure 1 bar) |
| Gumming | Roller pressing gumming |
| Diameter of roller | 60mm |
| Dev. replenishment | 0-1L per plate |
| Dev. heating-up rate | 0.5 degree C. per minute |
| Horizontal adjustment | Adjustable |
| Power supply | 220V single phase 50-60Hz |
| Power consumption (kwh) | 3.5 | 4.5 | 5 | 6 |
| Voltage fluctuation | within 10% |
| Gross weight(kg) | 500 | 650 | 780 | 900 |
| Net weight(kg) | 400 | 550 | 650 | 770 |
| optional | water wash recycle pump
automatic plate stacker
plate conveyor |
