Custom One Stop Circuit Board Design

Name: Custom One Stop Circuit Board Design
Brand: all-electronics-online.com
SKU: 691466691
Availability: InStock
Rating: 4.9 (60 reviews)

Price:	US $ 1-20pcs
Min Order:	1pcs
Pay Type:	T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	Circuit Board Design-002
Item:	Assembly PCB Electronic PCB Assembly Charger PCB
Layer:	1-22
Surface Finishing:	HASL, Enig, OSP, Immersion Au, AG, Sn
Min.Hole Size:	0.1mm
Min.Line Spacing:	3 Mil
PCBA QC:	X-ray, Aoi Test, Function Test(100% Test)
Port:	Shenzhen/HK/Guangzhou
Specialised:	LED, Medical, Industrial, Control Board
Delivery:	PCB, 7-10 Days;PCBA, 2-3weeks
Type:	Combining Rigid Circuit Board
Dielectric:	FR-4
Material:	Fiberglass Epoxy Resin + Polyimide Resin
Flame Retardant Properties:	V0

Product Description

custom one stop Circuit Board Design

Company Information

Shenzhen SHTL Tech Co., Ltd (HK SHTL Co., Ltd), an electronics manufacturing service provider and printed circuit board manufacturer, offers custom-designed electronics manufacturing and MID-sized OEMs and ODMs. A wide range of end markets that include PCBAs for Automotive, Communications, Computing, Consumer, Industrial, and Healthcare All these PCBAs are being exported to foreign markets, mainly to eastern Europe market. SHTL is dedicated to being a long-term PCBAs partner with our customers to achieve quality and cost optimization.

A professional PCB& PCBA design, product, sale manufacturer, established in 2010. Specially dedicate to Security, Industrial Automation, Medical, Household Appliance PCBA and Electrics products finished assembly. Currently with 100 workforce and covering 2, 000 square meters area, our products exported worldwide including North American, & South American, European Countries and Asia, etc.

PCB Technical standard:

PCB Item	Manufacture Capacity
Layer Counts	1--20L
Base Material	FR4, High-TG FR4, CEM3, aluminum, High Frequency(Rogers, Taconic, Aron, PTFE, F4B)
Material Thickness(mm)	0.40, 0.60, 0.80, 1.00, 1.20, 1.50, 1.60, 2.0, 2.4, 3.2
Max board size(mm)	1200X400mm
Board Outline Tolerance	±0.15mm
Board Thickness	0.4mm--3.2mm
Thickness Tolerance	±8%
Minimum line/space	0.1mm
Min Annular Ring	0.1mm
SMD Pitch	0.3mm
Holes
Min Hole Size(mechanical)	0.2mm
Min Hole Size(laser hole)	0.1mm
Hole Size Tol (+/-)	PTH: ±0.075mm; NPTH: ±0.05mm
Hole Position Tol	±0.075mm
Plating
HASL/LF HAL	2.5um
Immersion Gold	Nickel 3-7um Au: 1-5u''
Surface Finish	HAL, lead-free HAL, ENIG, Plated Gold, Immersion Gold, OSP
Copper
Copper Weight	0.5--6oz
Color
Soldermask	Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue
Silkscreen	White, Black, Blue, Yellow
Acceptable File Format	Gerber file, Powerpcb, CAD, AUTOCAD, ORCAD, P-CAD, CAM-350, CAM2000
Certificate	ROSH, ISO9001, UL

OFFICE

Five SMT Line

Two DIP Line

Our Services

Our professional engineering team can put your project into production in a short time. Sample pictures and BOM are needed to make customized products. Also we can supply for the copy of the PCB and PCBA, so you just sent me the enquiry is ok, we can do what you need to do!

SMT and DIP Equipment
Advanced SMT Equipment:
* HITACHI Screen Printer
* FUJI NXT- & FUJI XPF-L Modules
Assembly Production Machines:
* 2 automatic YAMAHA YS24 and YS12 SMT lines and 3 automatic MX400 and MX200 STM lines
* 2 DIP Dual wave soldering line
* 2 manual soldering production line
Capacity:
* 180 million points per month
Component range:
* 0201, 0402, 0603, 0805, 1206, 1608, 2125, 3216
* Fine Pitch QFP to 0.2mm
* BGA, Flip Chips, Connectors
* BGA to 0.2mm
Testing Equipment:
* Printing Solder Paste Test
* AOI(Automatic Optical Inspection)
* X-ray for BGA and QFN Testing
* Function Testing
* In Circuit Testing
* Testing Service

Every board is carefully examined by our dedicated inspection team using AOI and high magnification viewers. Using our X-ray machine, we test PCBs to component level and all wiring is fully inspected and tested. Flash testing and earth bonding tests can also be undertaken where required.

Packaging & Shipping

FAQ

Q: Does STHL technology Co., Ltd is a ture factory?
A: Of course, we are the true factory. Welcome to visit our factory at Shenzhen, and we can talk with skype video to visit our factory at frist.

Q: Do you have a capability to offer one-stop service, include ODM?
A: Yes, STHL company have 4 hardware engineers 6 software engineers and 2 structural engineers. Can offer ODM product include industry control, smart home. Instrumentation, and so on.

Q: How can you make sure the components quality?
A: We buy the components from the A-level agents, and have IQC workers test

Q: Do you have ISO9001 certificate?
A: Yes, STHL passed the UKAS ISO9001.

Q: How long is the delivery time?
A: Make PCB board need 7-12workdays, and PCB assembly need 3-5workdays, Test the function need 1-2workdays.

Q: Which way to ship?
A: Ship by DHL, UPS, TNT, FedEx, EMS etc, 3-4days arrive.

Why choose us

Shenzhen STHL Technology Co., Ltd.

A professional PCB& PCBA design, product, sale manufacturer, established in 2010. Specially dedicate to Security, Industrial Automation, Medical, Household Appliance PCBA and Electrics products finished assembly. Currently with 100 workforce and covering 2, 000 square meters area, our products exported worldwide including North American, & South American, European Countries and Asia, etc.

We have 4 strong and professional, R&D engineers, 6 SMT production lines 2 DIP production lines, 1 final assembly production lines and many advanced testing instruments. Our current annual production capacity is more than 4, 000, 000 PCS PCBA (circuit control board) and 100, 000 sets electronic end products assembly. Relying on high quality, high efficiency, and prompt way, we can provide various, multi-layer, customized PCBA, Final assembly and tailor-made service to our customers. Small and medium orders. Also be welcome.

Main Products:

1. PCBA OEM

PCBA Application:

*Telecommunication PCBA: Exchange Board, Router, GPRS

*Automation PCBA: Automatic Refueling Machine, Automatic Cutter, Inverter, Electricity Monitoring System, Frequency Conversion Controller, Electric Welding Machine, Elevator, Escalator

*RFID technology: Active RFID, Passive RFID

*Power Supply and New Energy: Industrial Power Supply, LED Driving Power, Solar Power System, Wind Power System

*Medical Equipment PCBA: Color Doppler Ultrasound Instrument, Medical Monitor

*Financial PCBA: Currency count machine, POS machine, Teller machine.

*Household Appliance PCBA: Coffee Maker, Blender, Soybean Milk Machine, Cleaner, Hair Straightener, Electric Toothbrush.

2. PCBA ODM: Embedded Industrial Control Product, Power Supply, Household Appliance Control Board

3. End Electronic Products Assembly and relative EMS

Metal, Plastic, Rubber or other material industrial design services.

Charnas has sophisticated R&D management system, Quality Assurance System, Supply Chain Management System, and Environmental Protection Management System. Based on our solid smartpower, considerate service, excellent core technology, added value service to customers, we have been approved and trusted by our home and abroad well -known customers. Company to pursue' Keep Searching for Development Innovation, Insist on keeping Improving, Charnas is on its way to be the best electronic products EMS company in the world.
