Custom PCB Double Layer PCB

Name: Custom PCB Double Layer PCB
Brand: all-electronics-online.com
SKU: 676726742
Availability: InStock
Rating: 4.7 (98 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	100/Piece
Pay Type:	T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	FEI223
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Rigid Circuit Board
Dielectric:	FR-4
Material:	Complex
Flame Retardant Properties:	V0

Product Description

Place of Origin
Guangdong, China (Mainland)
Number of Layers
Double layer PCB
Base Material
FR4 TG150
Copper Thickness
1/1OZ
Board Thickness
1.6mm
Min. Hole Size
0.35mm
Min. Line Width
12mil
Min. Line Spacing
16mil
Surface Finishing
Lead free HASL
Solder mask color
Black
Silkscreen color
White

Year Item	2015	2016E
Year Item	2015	Mass Production	Sample
Max. Multilay ers	20	20	24
Board Thickness Tolerance (mil/mm)	50±3mil / (±0.076mm); 14±2mil / (±0.05mm);	50±3mil / (±0.076mm); 14±2mil / (±0.05mm);
Min. hole size (mil)	Mechanical 6mil (0.15 mm), Laser 4mil (0.10 mm)	Mechanical 6mil (0.15 mm), Laser 4mil (0.10 mm)	Mechanical 6mil (0.15 mm), Laser 3.5mil (0.089 mm)
Finished Aspect ratio	12:1.	12:1.	16:1.
Min. line Width/Space (mil)	2.0/2.0mil; (0.050/0.050 mm)	2.0/2.0mil; (0.050/0.050 mm)	1.6/1.6mil;(0.040/0.040mm)
Impedance (ohm)	+/-10%	+/-10%	+/-7%
Dif f erential Impedance (ohm)	+/-10%	+/-10%	+/-7%
Gold Finger thickness(u"/um)	80u" (2um)	80u" (2um)	80u" (2um)
Router tolerance	±3.0mil (0.076mm)	±3.0mil (0.076mm)	±2.0mil (0.051mm)
Surf ace treatment	ENIG,H/G plating,OSP,Immersion sliver		ENIG,H/G plating,OSP,Immersion sliv er,Immersion Tin,ENEPIG
Application / Lamination
Standard and extended	FR4(TG140-180°),ANTI-CAF,Halogen Free, Low z-axis expansion(Lead Free)
Special perf ormance	High TG(BT)		High TG(BT),Low loss,FPCB material
High f requency	PTFE,Ceramic

Shenzhen Tengyuxin Technology Co., Ltd is a professional PCB & PCBA manufacturer which specialized in manufacturing SS, DS, HDI and multilayer PCB. Our modern factory is located in Qingyuan Guangdong which has more than 3000 staffs and 101, 000 square meters workshop. We can provide all-in -one service ( R&D, manufacturing and sales) for you
