| Prod Model: |
XWM |
| Type: |
Flexible |
| Material: |
PET |
| Application: |
Camera |
| Brand: |
OEM |
| Certification: |
SGS |
Product Description
Production description:
| Model NO | XWM | Origin | China |
| Feature | Intelligent | Protection | Waterproof, Dust-Proof, Insulation |
| Principle | Resistive | Wiring | Null Line and Live Line |
| Number of Switch | Multi Control Switch | Type | Flexible |
| Usage | Control Button | Structure | Overlay + Circuit +3m467 |
| Contact Type | Type a Contact | Kind | Single-pole on-off Switch |
| Brand | Singway | Detection Method | Retro-reflective Mode |
| Tail | 12 Way Zif Connector | Certification | SGS, ISO9001, UL,RoHS |
| P Grade | IP67 | Pitch | 1.0mm |
| Transport Package | Standard Export Packing | Trademark | Dongguan Singway Electronic Technical Limited |
| Specification | 60mm*80mm | HS Code | 8534009000 |
Advantages:1. Beautiful appearance, rich and bright in color, design can be arbitrary, the products can fully reflect
the individual style of the product itself and designer.
2. Panel can wash, good protection of durable color, characters, logos and other panel contents
without injury.
3. Small size, light weight, thin thickness, good tactility, abrasion resistant, installation and connection convenience.
4. Tightness is good, moisture-proof, dust-proof, waterproof, anti-oil, anti-corrosion and erosion of harmful gases proof, acid and alkali proof, quakeproof.
5. Low cost, high lifespan, membrane switchs design and manufacture are using the keyboard as a whole way, whether on the material or mold charges, the costs are lowest, the life expectancy of different types of membrane switch is more than 100 million times.
6. Easy to operate, intuitive, safe and reliable, In-house 100% functionally tested, components are guaranteed without any intermittent problem.
7. Customized specification is available and keys can make different shapes.
Technical Parameters 1.Electrical
| Maximun Circuit Rating: | 35V(DC),100mA,1W |
| Contavt Resistance: | 10Ω~ 500Ω |
| Insulation Resistance: | 100MΩ 100V |
| Dielectric: | 250VRms(50~60Hz 1min) |
| Contact Bounce: | < 5ms |
Life Expectancy: | Flat: ≥ 5million times |
| Tactile: ≥ 1 million times |
| Dura switch: ≥ 10million times |
2.Mechanical
| Actuation Force: | Flat:57~284g(2~10oz)
Tactile: 170~397g(6~14oz) |
Switch Strok:
| Flat: 0.1~0.5mm
Tactile: 0.6~1.5mm |
3.Environment
| Operation Temperature: | -40~+80 |
| Storage Temperature: | -40~+80 |
| Humidity: | 40,90%~95%,240hours |
| Vibration: | 20G,max.(10~200Hz,Mil-SLD-202,M204.Condition B) |
