| Prod Model: |
silicone |
| Name: |
Silicone Rubber Heater |
Product Description
Specifications for Silicone Rubber Heater | Temperature Rating | 250°C maximum operating |
| Size/Shape Limitations | Min size 20mm*20mm |
| Thickness | ~0.06 inch(Single-Ply)~0.12 inch(Dual-Ply) |
| Voltage | Any AC or DC |
| Wattage | Customer specified(Normal maximum of 0.8-1 watts per square mm) |
| Power lead wire | Silicone rubber, SJ Power Cord, or Teflon insulated stranded wire |
| Attachment | Hooks, lacing eyelets, Or Velcro closure. Temperature control(Thermostat) |
Description | 1. Thinness, lightness, sticky and flexibility
2. Improve heat transfer, accelerate warming and decrease power under the process of operation
3. Heat fast and high thermal conversion efficiency |
Features for Silicone Rubber Heater
(1) Heating fast and long time using
(2) Flexibility and customized shape
Dual Voltage, Zoning and Three Phase for Silicone Rubber Heater
Due to the flexibility in circuit design of Silicone Rubber Heater, multiple heating circuits can be designed to accommodate dual voltage and multiple zones. On dual voltage heaters, three leads, including a common in a different color, are provided for wiring the heater in series for the higher voltage and parallel for the lower voltage. 120/240 Vac or 240/480 Vac can be achieved. Multiple circuit areas can be zoned to achieve different heating effects. Three-phase circuits can also be designed for high current applications.
Our Services
One year warranty
Fast delivery and competitive price
FREE assistance for design to achieve an ideal thermal heating solution
Customized size,shape and voltage&wattage |
Features of Silicone Rubber Heater1. Maximum temperature resistantof insulation : 200 C degree
2. Best continuous working temperature as 150C degree, max temperature as 230C degree momentarily.
3. Power deviation : 8% insulation resistance : >= 5MΩ
4. Compressive strength : 1500V/5s
5. Standard dimension : width: 20mm-1000mm ; Length : 25mm-1000mm; lead wire length : 200mm.
6. Fast heat diffusion , uniform heat transfer , directly heat objects on ; high thermal efficiency , high strength ,
long service life ,work safe , uneasy for ageing.
Applications of Silicone Rubber Heater
1. Silicone rubber band heater can be used in damp , no explosive gas atmosphere, industrial equipment pipelines, heat preservation for can and barrel .
2. It can be used as a frozen prevention, air conditioner compressor ,assisting heating of elctrical equipment .
3. Also it can be used as medical equipmentand medical care (such as blood tube heater, blood analyzer, heat supplementary for corset and waistband).
Product application
1.Preheating devices for welding piers and iron steel& metal products
2.Generalmachinery manufacturer, anti-freeze heater for pumps
3.Heating pressures for shaping musical instruments plywood
4.Dampproofing and heating for large silos
5.Anti-freeze heater for oil pressure cylinder
6.Dust collector hopper.(For power dehumidifying)
7.Deyer's heater and medical instruments
8.Heating plates for coffer makers, and the others electriacl machinery and devices.
Superb Heater Technology has been focused on the production of insulation thermal rubber heating mat for medical equipment since 1985, which is well-known as one of the leading manufacturers and suppliers of insulation thermal rubber heating mat for medical equipment. In the past years, we owned strong reputation for the high quality, reliable performance and strong durability of our products. Should you are interested, please feel free to contact our factory.
Shenzhen superb heater technology Co., Ltd, Founded in 1985, Start is a state run Magnesium Oxide factory, After privatization reform To become a professional to provide all kinds of electric heating products of the comprehensive private joint-stock companies, After years of development company now grown to have include: ChaoHu heating material fitting, JiuDing machinery and spare parts, LiLin cartridge heaters, chaohu band coiling heaters, JXC Industrial heaters five plants, more than 200 employees, assets of more than $ 5 million, Products include various types of industrial heater, cartridge heater, hot runner, thermocouples, band heater and a variety of heater materials and heater equipment to meet customers one-stop shopping for all kinds of heating element, heating materials and heating equipment needs.
Over the years we are committed to technology and product quality improvement, many products similar products meet international quality, in China in the lead, swaged-in leads cartridge heater and diameter less 4mm cartridge heater as China's first single, cost-effective products to give our customers highly recognized, it has been to establish and maintain long-term cooperative relations with more than 700 customers in over 40 countries.
We will insist on our stable style to establish good image in both customers and our partners. We have been insisting on the "REDUCING THE COST AND GIVING ADVANGTAGE TO CUSTOMERS " To provide customers with better products and services, and grow with customers
After long-term accumulation, we have set up agents and partners in India, Dubai, USA, Russia, Brazil, Argentina, Thailand, Korea and other countries to provide convenient and quick service
