Customized Force Sensitive Resistor/Sensor. S402 S400 S406 S408

Name: Customized Force Sensitive Resistor/Sensor. S402 S400 S406 S408
Brand: all-electronics-online.com
SKU: 726226292
Availability: InStock
Rating: 4.8 (57 reviews)

Price:	US $ 3-7/Piece
Min Order:	1000/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	WEL-PR/S/B
Material:	Customized
Wiring Type:	Customized

Product Description

Product Description
Force Sensitive Resistor are resistive sensor exhibiting vary resistance that responds to force applied to the sensing area. As force on the sensor is increased, resistance is decreased.
For the single-zone sensors, as the sensor is a Two-terminal device that can essentially be treated as a variable resistor whose value is controlled by applied force, and also a switch whose threshold is controlled by applied force and setting up.
The sensors are made up of robust polyester film, high-conductive material and Nano-sized force sensing material. The top layer of the sensor consists of the area of force sensitive layer on a flexible film. And bottom layer is comprised of conductive circuit traces on a flexible film. And the above two layers are s are stick together by spacer adhesive and active area is without adhesive. When the active area is applied force, force sensitive layer on the top layer shunts the circuit traces on the bottom, varying resistance output terminals.
Static / dynamic pressure sensing
Quick response
Durable long life
Customized design

Thickness:0.42mm
Shape:Flexible
Actuation force:20g Res.<=200KΩ
Sensitivity range:20g to 6Kg
Resolution:continuous
Non-actuated resistance:>10M Ω
Response time:<10ms
Operating temperature:-40ºC~+85ºC
Life time:>1 million
Repeatability Same part:+/-3%,Average R@1000g
Repeatability part to part:+/-10% Average R@1000g
Hysteresis:+10%,@1000g,(RF+ - RF-)/FR+
EMI:Generates no EMI
EDS:not ESD sensitive
Drift:<5%, 2.5kg load, 24H

Thanks advise us your concern, We will customized it and update datasheet
We are happy to provide samples before mass production.
