Customized ID 1200mm Large Through Hole Slip Ring

Name: Customized ID 1200mm Large Through Hole Slip Ring
Brand: all-electronics-online.com
SKU: 664531595
Availability: InStock
Rating: 5 (42 reviews)

Price:	US $ 1100/Piece
Trade Terms:	FOB
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	BTH1200
Inner Hole:	3mm ~1200mm
Circuits:	2~250
Operating Temperature:	-40c~ +100c
IP Grade:	as Per Requested
Contacting Material:	Copper
Connector:	Wires or Pins

Product Description

ID 1200mm Large Through Hole Slip Ring with Customization

Apart from the standard through hole slip rings, we offer our unique slip rings in tailor-made structures as per your special application requirements. The engineering staff utilizes its 20 years of expertise in slip rings to offer you what you have been looking for. A wide range of slip rings are produced in different sizes, shapes, volumes metal types and applications.

Reliable for CT Machine
Heavy industry
Military application

Inner hole diameter can be high to 1200mm

Parameters:
Mechanical :

Working speed	As per requested
Operating temperature	-40ºC~ +100ºC
Contact material	Precious metal
IP Grade	IP54

Electrical:

Circuit	2 ~250
Current	2A, 5A, 10,15A,20A,30A optional
Signal	As per requested
Voltage	≤380V, 600V optional
Dielectric strength	≥1000V@50Hz between each circuit
Insulation resistance	1000MΩ@ 500VDC
Electric noise	≤7mΩ
Lead wire size	As per requested Wire or Metal Pin
Lead wire length	Standard in 200mm

Features of Large through hole slip rings :

Inner hole big to 1200mm diameter
Compliance with standard through hole slip ring design
Conduct safe and reliable
Easy installation and convenient delivery
Workable in hostile environment(-40°C~ +100°C)

Benefit of Large through hole slip rings from ByTune:

Prompt delivery
Affordable price
Quality guaranteed
Superior after-service
long life-span

Alternatives of Large through hole slip rings:

Inner hole diameter high to 1000mm
Circuits
Loading of each circuit
Connect way
Different signal compatible
Higher IP grade
Working speed

ByTune electronics Co., Ltd, since 1998, is a government supporting, hi-tech, private enterprise, with more than 200 employees, 20, 000 square feet factory and 2, 500 square feet rd & sales office. ByTune is focused in developing, designing, manufacturing slip rings nearly 20 years, we supply wide range slip rings and provide360° Rotary solutions. Besides supplying standard through hole slip rings, capsule slip rings, separate slip rings, pan cake slip rings, hydraulic slip rings, pneumatic slip rings, coax rotary joints, fiber optic slip ring etc, we have an expertized engineering team of more than 50 persons, we provide full range of customized slip rings at prompt delivery. We customize slip rings as per customers request in different applications such as agriculture machine slip ring, crane slip ring, antenna slip rings, wind turbine slip rings, auto-wrap machine slip rings...

ByTune electronics is equipped with the machines of CNC ( 2, 3, 4 and 5 axis), vertical machine tool integrating turning with milling, auto-drilling machine, precise milling machine, numerical control punch press, grinding machine, and so on… ...With advanced machines, we could do all of the processions in one-stop: CNC lathe, milling, drilling, grinding, punching, bending, casting, forging, stamping, etc … ByTune supplies quality & precise machine parts at prompt delivery.

At www.btslipring.COM, you could get high quality slip rings and machine parts at an affordable price and with superior support by contacting sales@btslipring. COM.

ByTune is ISO9001, CE, FCC, RoHS and military standard JGB9001A certificated!
