| Prod Model: |
XWM16 |
| Rear Adhesive: |
3m467,3m468,etc |
| Size: |
Customized Size Accepted |
| Matching Color: |
Pantone No. |
| Type: |
Convex |
| Material: |
Rubber |
| Application: |
With Remote Control |
| Structure: |
Rubber |
| Detection Method: |
Electrometry |
| Brand: |
Singway |
Product Description
We are the professional of manufactory and export Touch Screen,Touch Panel,Membrane Switch,Rubber Matte and Flexible Printed Board and some relative electronic products,we have profuse design with your drawings or requirements,if you are interested in any products of our catalogues please do not hesitate to email us.We are promise that the quality is good and the price is favourable.
Item Details:
1,All manufacturing processes confirm to the ISO-9001/TS16949/ISO13485 standards
2, RoHS directive compliant green products "lead free initiative"
3, Smooth and good touch feeling
| LAYER CONSTRUCTION and Performance |
| CONSTRUCTION | Material | THK(mm) |
| Graphic Overlay | PC | 0.25mm |
| Spacer tape | 3MHVB | 0.13mm |
| Upper circuit | PET | 0.075mm |
| Spacer tape | 3M467 | 0.05mm |
| Lower circuit | PET | 0.125mm |
| Rear Adhesive | / | / |
| Resistance | <150OHMS | |
| Pitch | 2.54mm | |
| Silver Paste | NJ-SP-P1501 | Transparent Silver |
| Carbon Paste | ED423SS/CI2001 | |
| Insulating Ink | ED452SS/DI7502 | |
| LED | / | |
Lead time:
★To create and submit counter-drawings + artwork for your approval:2-3 work days
★To build tooling and Sample Shipping:8-10 days
★Mass Production Delivery:15-30 days after the sample confirmation
Packaging Details:
1) Wrap in air bubble film
2) Put into foam box and each unit with label marked
3) Packed with extra carton box, which make sure the goods safety in transportation.
4) We accepted Customized package.
Shipping Details:
1) Can Ship by express such as DHL, FEDEX, EMS, TNT, UPS, or by Sea, by air, it's depends on your requirement.(The express shipping time is about 3 to 7 working days.)
2) The tracking number will be informed after 1 day the package delivered.
3) We will follow the shipment after we sent it. If you not receive goods on time, please contact us immediately, we will assist to get the goods smoothly.
Payment terms:
1.First 3 dealings: payment term is Cash On Delivery(C.O.D.), we accept Bank T/T for payment.
2.After the first 3 dealings: payment term is 30 days or 60 days.
Our Service
1.Your email will be replied within 24 hours during the working time.
2. Whenever, we are pleased to get your order and any relevant requests.
3. Ensure the products meet the quality standards.
4. Ensure the goods will be delivered on time.
5.Your own label,we could use your label,with your company name and details.
6. Provide warm and friendly service and after-sale service.
7. About the warranty, if you have any problem about the goods after received it, you can tell us on time. We will make sure to give you a satisfactory solution.
8. For more details and latest price, please feel free to contact us.
A membrane switch is light touch keyboard by using a series of layers of polymer films and adhensives. It consist of 6 layers, called graphic overlay, overlay adhesive, upper circuit layer, circuit spacer, lower circuit layer and back adhesive. Membrane switch has a good waterproof, dustproof,prevent the erosion of harmful gas.Membrane Switches are widely used in various electronics fields such as Industrial controls, measurement instruments, fitness equipment, medical devices, chemistry and metallurgy, testing equipment, electronic scale, environmental protection equipment, appliances, building safety system and fire alarm system.
Process and packing
Design ---- Cutting Material ---- Printing Down ---- Ink ---- Screen Printing ---- Oven Drying
---- Printing Inspection ---- Die Cutting ---- Punching ---- Assembly ---- Testing ---- Inspection
FAQ:
Q: Are you trading company or manufacturer ?
A: We are a factory with 3000 square meters and have more than 10 years manufacture and sales experience.
Q: Why us ?
A: 1. Real manufacture directly supply to guarantee competitive price
2. OEM& ODM service offered
3 Professional Engineer team
4 high-tech manufaturing CNC
5 Quality assurance and good after sales service .
Q: What you need to give us ?
A: Please offer us 2D or 3D drawings (with material, dimension, tolerance, surface treatment and other technical requirement etc.) ,quantity, application or samples. Then we will quote the best price within 24hours. .
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Q:How to know my products going on without arrival your factory
A:We make products totally according to drawings or samples strictly until your 100% confirmation ..We are aim to long time business partner ,not one time cooperation
Q:What is your MOQ ?
A:We never care the order size ,pls no worry ,any qty is available
| Item Name | Customized tactile waterproof push button membrane switch |
| Overlay Material | PET(polyester),PC(polycarbonate) |
| Oil Ink | SEIKO, JUJO, DUBUIT, PROELL, NORCOTE UV |
| 6 Layers Metal dome Type Membrane Switch Structure | Overlay + Spacer + Dome Retainer + Spacer + Circuit Layer+ Rear adhesive |
| 4 Layers Polydome Type Membrane Switch Structure | Overlay + Spacer + Circuit + Rear adhesive |
| Printing | Screen printing |
| Surface | glossy surface or matte surface |
| Size | As require ,OEM service |
| Silver Paste | CHANGSUNG: CSP-3163, CSP-3352, CSP-5150;
ACHESON: ED 725A(6S-61), ED 427SS, ED 479SS, ED 976SS HV;
FUJIKURA and OTTI |
| Expectancy | tactile type≥0.5 million times |
| Operation Force | 15~750gf |
| Stroke Switch | 0.1~0.4mm (no touching) |
| Recoil time | ≤10ms |
| Tail bending performance | ≤180° |
| Window | with clear or transparent window |
| Life | flat type≥1 million times |
| Rear adhesive | 3M467,3M468,3M9080 ect |
