Cx-Flm-RF-3002 Small Float Level Switch

Name: Cx-Flm-RF-3002 Small Float Level Switch
Brand: all-electronics-online.com
SKU: 749931095
Availability: InStock
Rating: 4.4 (21 reviews)

Price:	US $ 15/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	1/Piece
Pay Type:	T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	CX-FLM-RF-3002
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Install Mode:	Optional
Float Ball Size:	Optional
Temperature:	-20~100c
Switch:	Nc/No
Power Supply:	220V
Accuracy Error:	±2mm (in Water)

Product Description

CX-FLM-RF-3002 Small float level switch

Brief introduction
1.Adopt SUS304/316 stainless steel
2.Simple structure , conveniently usage's level control parts ,
3.It has high temperature resistance, long working life ,stable performance
4.Mainly used in hot water inside the appliance or mechanical ,such as water heaters ,water dispenser ,dishwasher ,electric water ,oil compressor ,air compressor and other mechanical equipment

.

Main parameters

Installation	Side-mounted
Installation screw	M10,can customize inG1/8"
Electric connection	300mm, UL1430 AWG22
Bar material	SUS304
Float material	SUS304
Working pressure	6 Bar
Working temperature	-20~80ºC
Accuracy	+/-2mm (in the water)
Repeatability	+/-1mm (in the water)
Switch type	N.C./N.O
Work voltage	250VAC,200VDC
Work current	0.70A
Switch power	70VA
Durability	100000times
Float dimension	Dia.28 * dia.9.50*28

Cixi flowmeter Co., Ltd. Was established in 2008 and since then has been dedicating itself to research and manufacture of various kinds of flowmeter. With sophisticated experience in technology and management, CIXI Flowmeter has made a name for itself as an excellent manufacturer of various kinds of flowmeter. In 2007, we have especially set up Shanghai Cixi Instrument Co. Ltd for handling the deals of Export.

Thanks to outstanding performance of products, CIXI Flowmeters are being applied in more and more fields where there' S liquid to measure. CIXI Flowmeters have found users in many countries besides China, such as Malaysia, India, Thailand, Vietnam, South Africa and so on. Increasing number of users are finding that CIXI Flowmeter are kind of product with super performance and reasonable price.
