Cx-Flm-RF-Mhg Side-Mounted Float Level Switch

Name: Cx-Flm-RF-Mhg Side-Mounted Float Level Switch
Brand: all-electronics-online.com
SKU: 750017875
Availability: InStock
Rating: 4.4 (28 reviews)

Price:	US $ 15/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	1/Piece
Pay Type:	T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	CX-FLM-RF-MHG
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Install Mode:	Optional
Float Ball Size:	Optional
Temperature:	-20~100c
Switch:	Nc/No
Power Supply:	220V
Accuracy Error:	±2mm (in Water)

Product Description

CX-FLM-RF-MHG Side-mounted float level switch

Main features

Can be directly installed on the vessel wall point and It is very convenient to install
The switch adopt stainless steel material and isolate with the outside
So it has long working life ,anti-explosion ,anti-corrosion and other characteristics .

Main parameters

Installation	Horizontal side mounted ( G1 is exterior,G2 is inbuilt)
Installation screw	G1 is NPT1/2",G2 is M10~M16
Electric connection	300mm, UL1430 AWG22
Material	SUS304
Application ration	Above 0.65
Working pressure	20 Bar
Working temperature	-10~80ºC
Accuracy	±2mm (in the water)
Repeatability	±1mm (in the water)
Form switch	N.C./N.O
Working voltage	250Vac, 200Vdc
Contact capacity	0.7A/50W/SPST
Working life	107
Float dimension	Dia.17 * 55
