Cx-Wr Thermocouple with Threaded Connector

Prod Model:	CX-Wr
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Temperature Range:	-200-1800c
Fixing:	Thread/Flange/None
Connection:	Terminal Box/Compensation Cable/Plug
Probe Length:	Custom
Thermocouple Wire Element:	Simplex/Duplex

Product Description

Thermocouple with Threaded Connector


Brief introduction:

It is usually connected with display meter, recording meter and computer ect.
To directly measure the temperature of liquid, vaper, gas and solid surface
ranging from 0 to 1300°C during various production processes.

How to choose?
1.Diameter and length:Can be customized as customer's requirements
2.Junction box: water-proof type, splash-proof type, anti-explosion type, connector type,import type.
3.Fixed device: flange/none/screw.
4.Temperature Range: 0-1800 centigrade .
5.Terminal blocks: terminals box

Selection table:

Type	Graduation	measuring range	thermal response time	protection tube material	specification
					d	L
WRM-220 WRM2-220	N	0-800	<90S	1Cr18Ni9Ti	Φ16	300*150 350*200 400*250 450*300 500*350 550*400 650*500 900*750 1150*1000 1650*1500 2150*2000
		0-1000		0Cr25Ni20
WRM-220G WRM2-220G		0-800	<24S	1Cr18Ni9Ti
		0-1000		0Cr25Ni20
WRN-220 WRN2-220	K	0-800	<90S	1Cr18Ni9Ti
		0-1000		0Cr25Ni20
WRN-220G WRN2-220G		0-800	<24S	1Cr18Ni9Ti
		0-1000		0Cr25Ni20
WRE-220 WRE2-220	E	0-800	<90S	1Cr18Ni9Ti
WRE-220G WRE2-220G			<24s
WRC-220 WRC2-220	T	0-350	<90s	1Cr18Ni9Ti
WRC-220G WRC2-220G			<24s
WRF-220 WRF2-220	J	0-600	<90s	1Cr18Ni9Ti
WRF-220G WRF2-220G			<24s
WRM-221 WRM2-221	N	0-800	<20s	1Cr18Ni9Ti	Φ20
		0-1000		0Cr25Ni20
WRM-221G WRM2-221G		0-800	<24s	1Cr18Ni9Ti
		0-1000		0Cr25Ni20
WRN-221 WRN2-221	K	0-800	<120S	1Cr18Ni9Ti
		0-1000		0Cr25Ni20
WRN-221G WRN2-221G		0-800	<24S	1Cr18Ni9Ti
		0-1000		0Cr25Ni20
WRE-221 WRE2-221	E	0-800	<120S	1Cr18Ni9Ti
WRE-221G WRE2-221G			<24S
WRC-221 WRC2-221	T	0-350	<120S	1Cr18Ni9Ti
WRC-221G WRC2-221G			<24S
WRF-221 WRF2-221	J	0-600	<120S	1Cr18Ni9Ti
WRF-221G WRF2-221G			<24S

Type 220,221 for anti-spray type, protection class IP65;
We also produce the thermocouple with protection tube of other material.
Normal pressure is 10Mpa.

Model type	thread specification		d
	code	M
WRN-220		M27*2	Φ16
WRN-220A	A	G3/4
WRN-220C	C	NPT3/4
WRN-221G		M27*2	Φ20
WRN-221GA	A	G3/4
WRN-221GC	C	NPT3/4

Type	Graduation	measuring range	thermal response time	protection tube material	specification
					d	L
WRM-230 WRM2-230	N	0-800	<90S	1Cr18Ni9Ti	Φ16	300*150 350*200 400*250 450*300 500*350 550*400 650*500 900*750 1150*1000 1650*1500 2150*2000
		0-1000		0Cr25Ni20
WRM-230G WRM2-230G		0-800	<24S	1Cr18Ni9Ti
		0-1000		0Cr25Ni20
WRN-230 WRN2-230	K	0-800	<90S	1Cr18Ni9Ti
		0-1000		0Cr25Ni20
WRN-230G WRN2-230G		0-800	<24S	1Cr18Ni9Ti
		0-1000		0Cr25Ni20
WRE-230 WRE2-230	E	0-800	<90S	1Cr18Ni9Ti
WRE-230G WRE2-230G			<24s
WRC-230 WRC2-230	T	0-350	<90s	1Cr18Ni9Ti
WRC-230G WRC2-230G			<24s
WRF-230 WRF2-230	J	0-600	<90s	1Cr18Ni9Ti
WRF-230G WRF2-230G			<24s
WRM-231 WRM2-231	N	0-800	<20s	1Cr18Ni9Ti	Φ20
		0-1000		0Cr25Ni20
WRM-231G WRM2-231G		0-800	<24s	1Cr18Ni9Ti
		0-1000		0Cr25Ni20
WRN-231 WRN2-231	K	0-800	<120S	1Cr18Ni9Ti
		0-1000		0Cr25Ni20
WRN-231G WRN2-231G		0-800	<24S	1Cr18Ni9Ti
		0-1000		0Cr25Ni20
WRE-231 WRE2-231	E	0-800	<120S	1Cr18Ni9Ti
WRE-231G WRE2-231G			<24S
WRC-231 WRC2-231	T	0-350	<120S	1Cr18Ni9Ti
WRC-231G WRC2-231G			<24S
WRF-231 WRF2-231	J	0-600	<120S	1Cr18Ni9Ti
WRF-231G WRF2-231G			<24S

Type 230,231 for water-proof type, protection class IP55;
We also produce the thermocouple with protection tube of other material.
Normal pressure is 10Mpa.

Model type	thread specification		d
	code	M
WRN-230		M27*2	Φ16
WRN-230A	A	G3/4
WRN-230C	C	NPT3/4
WRN-231G		M27*2	Φ20
WRN-231GA	A	G3/4
WRN-231GC	C	NPT3/4

Diagram:
It can be suctomized according to your requirements.
