Cylinder Type Inductive Proximity Sensor Switch Lm12

Cylinder Type Inductive Proximity Sensor Switch Lm12
Price: Negotiable/Piece
Trade Terms: CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union,Paypal,Money Gram
Prod Model: LM12
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Detection Distance: 2mm
Detection Object: Iron 12X12X1mm
Response Frequency: DC:0.5kHz,AC:25Hz
Shell Material: Metal
Protection Grade: IP67
Certification: CE

Product Description

Structural categoryCylinder type
Outward appearance codeLM12
FlushDetection distance2mm

DC
6~
36
VDC
  NPNNOLM12-3002NA
NCLM12-3002NB
NO+NCLM12-3002NC
  PNPNOLM12-3002PA
NCLM12-3002PB
NO+NCLM12-3002PC
Two wire systemNOLM12-3002LA
NCLM12-3002LB

AC
90~
250
VAC
SCR
controllable silicon
NOLM12-2002A
NCLM12-2002B
NO+NC
Relay output
Non-flushDetection distance4mm

DC
6~
36
VDC
NPNNOLM12-3004NA
NCLM12-3004NB
NO+NCLM12-3004NC
PNPNO  LM12-3004PA
NCLM12-3004PB
NO+NCLM12-3004PC
Two wire systemNOLM12-3004LA
NCLM12-3004LB

AC
90~
250
VAC
SCRNOLM12-2004A
NCLM12-2004B
NO+NC
Relay output
 DC200mA
SCR/Relay300mA
Output voltage dropDC/ACDC< 3V, AC< 10V
Consumption currentDC< 15mA,   AC< 10mA
Standard detected object15× 15× 1(A3 )
Repeated precision0.01
DC/AC Response frequency400Hz/25Hz
Working environment temperature-25 ~+75
Insulation resistance≥ 50MΩ
Shell materialMetal
Protection gradeIP67
Altemative model at home and abroadE2E-X5M

Yueqing Trihero Elecric is located in "Capital of China's low-voltage electrical appliances, " the Liuzhou City, is a collection of scientific research, development, production and sales as one of the non-regional joint-stock enterprises.

The company mainly produces relays, instruments, sensors, circuit breakers, frequency inverter and other products, has now extended to manufacturing plastic products, filter paper, and other diversified development. The company's industrial park covers an area of 7, 300 square meters, with a number of joint ventures and holding enterprises, its brand "Trihero" is in the industry favored. The company's quality system complies with international standards, in the same industry enterprises is the first to pass ISO9001: 2000 international quality management system and the CE, RoHS certifications.

After years of operation, our products are sold to more than 60 countries, we have built many overseas network with the help of local partners to meet the customer diversified demands.

With the development of society, we will work harder to provide customers with reliable, stable products and a full range of professional services. Our goal is: To become the user trust, with first-class scientific research and development capabilities of high-tech enterprises, and always pragmatic innovation, forge ahead spirit, to create a century Sanying and make unremitting efforts!
