| Prod Model: |
YET428PC |
| Ransmitting Frequency: |
315m/433.92m/Oters |
| Use Range: |
Industrial ,Car,Motorcycle,Door Opener,Windows Con |
| Static Working Current: |
≤6mA |
| Oscillation Resistance: |
Under Your Requests |
| Remote Controlcapacity: |
400 |
| Sensitivity: |
≥-105dBm |
| Receiving Sensitivity:≥: |
-112dBm |
| Working Temperature: |
-40°c - +80°c |
| Control Voltage: |
AC/DC 12V/24V |
| Channels: |
2 Channel |
| Application: |
Alarm |
| Signal Transmission: |
RF Remote Control |
| Type: |
Button |
| Certification: |
CE |
| Universal: |
Universal |
| Transmission Distance: |
50-100m |
| Material: |
Plastic |
| Voltage: |
12V/24V |
| Battery Type: |
No Battery |
Product Description
DC 12v/24V Auto wireless 433mhz Remote Controller YET428PC
1. Brief introduction
Our factory design and produce the one channel wireless intellect receiving control what can provide switch signal to the relay, so it can meet many requirements such as: the connection and lock of the switch and other special control programs. This kind of wireless intellect receiving control main apply to auto door, curtain, lifting appliance, gate way, lifter, industrial control and security field.
This kind of wireless receiving control is high confidentiality, large memory space, stable characteristics, low power consume and very convenience, it is unnecessary adopt the traditional wire jumper or dip switch code but only receive and store the wireless signal from the remote control, and The lost learnt control can't work if you delete the memory message of the receiving control, however, it should learning again by the owner if want to obtain the right of use.
2. The way of output
A. Keeps 8 seconds-- "1" connect
B. Self-lock control -- "2" connect
C. Interlock -- "3" connect
D. Inching control--disconnect
(check the Circuit diagram for details)
3. Learning way and steps
Learning fixed code & learning code:
1. Press learning key of receiver-the pilot lamp light-release learning key and pilot lamp extinguish , indicate enter into the status of learning.
2. Press any button of the remote control, indicate learning success as the pilot lamp flash 5 times and automatically exit learning state. Receiver automatically exit learning state if you do nothing in 32 seconds. (Can store 30pcs this type remote control)
Learning rolling code:
- Press learning key of receiver-the pilot lamp light-release learning key and pilot lamp extinguish , indicate enter into the status of learning first time.
- Press any button of the remote control, indicate first time learning success as the pilot lamp keep flashing slowly.
- Repeat the operation of step "1", enter into the status of learning second time.
- Press the same button in step "2", the pilot lamp flash 5 times, learning successful. (Can store 6pcs this type remote control)
4. Delete memory messagePress the learning key of the receiver-pilot lamp light-hold on pressing over 8 seconds until the pilot lamp extinguish, which indict success to delete the memory message.5. Main Technique Data| Working voltage | DC12V/ 24V (optional) |
| Static working current | ≤7mA |
| Working temperature | -40ºC to +80ºC |
| Receiving sensitive | ≥-105dBm |
| Working frequency | 315MHz,433MHz (optional) |
| Contact current | ≤10A |
| Relay capacity | 10A 250VAC or 10A 30VDC |
| Receive the type of encoding | a. encode learning code and fixed code b. encode rolling code alone (optional "a" or "b") |
| Maximum storage for transmitter | 30pcs of learning or fixed code; 6pcs of rolling code |
| Size | 62mm*43.5mm*30mm |
Packing & Delivery
| Packaging Details | 1. PC bag with master carton, 500PCS per case
2. Blister package with master carton
3. White box with master carton
4. Color box with master carton |
|---|
| Delivery Time | 3~7 working days after received payment |
|---|
Our Service
1. Your inquiry related to our products or prices will be replied in 12 hours
2. Well-trained and experienced staffs to answer all your enquires in fluent English
3. OEM&ODM,any your customized products we can help you to design and put into production
4. Protection of your sales area, ideas of design and all your private information
5. Deliver by air mail or ship for your orders.
Extra service:
1. Logo printed
2. Sample for testing could be arranged
3. Sample could ship out by DHL,FEDEX or TNT or EMS in 3 days after confirmation.
FAQ
Q1:How can I find a suitable module?
A: Please show us the frequency (433.92MHz is the most common frequency) and chip (fixed code, learning, rolling code or duplicator). OR take a clear picture of the PCB board, and pass it to us, we will help you find it and recommend the right items.
Q2: May I have samples for testing?
A: Yes, samples are available and they will be ready in 3 working days, please check the model and code & frequency needed.
Q3: How to program it?
A: The programming is different from code to codes, we can provide you a manual or video
Shenzhen yaoertai Technology Co., Ltd established in 2005 and specialized in home automation remote control, controller, receiver module and other security accessories.
We always make great efforts to develop new products to meet different market and demands. Our factory Located in Shenzhen city so we can enjoy convenient transportation. Our company occupies an area of 1, 000 M2. There are Six production flows in our factory, which is SMD, Reflow Soldering, Parts Inserting, Post Soldering, assembly and Packing. Strictly quality control is performed in every procedure from material sourcing, processing, and testing to packing. Our annual production capacity is 4, 000, 000PCS and all our products certified with CE, RoHS.
Our products gain wide praises from domestic and abroad! Our main market is Middle East; European, Southeast Asia and South America. OEM and ODM orders are welcomed. Please contact our sales team for products selection or customized services. We will try our best to satisfy you! Reliable quality and best service is our pursuit!
We warmly welcome customers from domestic and abroad to establish business relationship and create a bright future with us!
