DC 12V500va for Solar System Pure Sine Wave Power Inverter
| Price: |
Negotiable/Piece |
| Min Order: |
100/Piece |
| Pay Type: |
T/T |
| Prod Model: |
DC 12V500VA |
| Power: |
500va |
| Charging Current: |
15-20A |
| Inverter Output Voltage: |
110V/230V+/-3% |
| Trade Mark: |
Tiger Head |
Product Description
PURE SINE WAVE INVERTER
DC 12V500VA
POWER: 500va
CHARGING CURRENT :15-20A
DC VOLTAGE INPUT:12v
Inverter Output Voltage:110v/230v+/-3%
Output Waveform: Pure sine wave
Transfer Time:Automatic switching within 4ms.
Overload Capacity:120% for 10min,150% for 1min
Protection Funtion Short circuit protection,overload protection,over temperature protection,battery protection against reverse connection(reverse connection protection)
| DISCRIPTION |
| Power | 300W/500VA |
| AC input range | 90V-280VAC |
| Charging current | 15-20A |
| DC voltage input | 12V |
| Input frequency range | 50/60hz±3% |
| Regulated voltage output | AVR 220V± 5% |
| Inverter output voltage | 110V/230v±3% |
| Inverter output frequency | 50hz±1% |
| Output Waveform | Pure sine wave |
| THD | ≤3% |
| Transfer Time | Automatic switching within 4ms |
| conversion efficiency | 85% |
| Overload capacity | 120% 10min 150% 1min |
| Cooling mode | Forced air cooling |
| Altitude used | ≤1000m(lower the capacity when the altitude is higher than 1000 meters) |
| Relative Humidity | 30%-90% |
| Operating Temperature | 0--40ºC |
| Product Dimension | (L*W*H ) 30*19*5*21.5cm |
| Out Packing Dimension | |
| Net Weight(kg) | 5.8 |
| Gross Weight (kg) | 6.8 |
| Noise(dB) | 40-60 |
| Protection Function | Short circuit protection, overload protection, over voltage protection, under voltage protection, over temperature protection, battery protection against reverse connection (reverse connection protection) |
Guangzhou Tiger Head Battery Group Co., Ltd. is situated in the Huangpu road, Tianhe District, Guangzhou, with its east neighboring to the Huangpu Port, its west to the Guangzhou East Train Station, the Exit to the Huanan Express Trunk Way, and its south facing the Pearl River. Thus it boasts of convenient transportation in both highways and waterways.
Guangzhou Tiger Head Battery Group Co., Ltd. is an export-oriented enterprise specializing in battery production and management, with the largest scale in Chinese battery industry. It realizes annual output of 2 billion pieces of dry batteries and earns over 308 million U. S. Dollars of foreign exchange per year, which makes it the leading battery enterprise in China.
The company' S main products are "555", "Tiger Head" and " TIHAD" brand all kinds of dry batteries, lead-acid storage batteries, Ni-MH batteries, polymer Li-ion batteries and some battery-related appliances.
The trademark "Tiger Head" of the company is the first "Chinese Well-known Trademark" in Guangzhou as well as in the country' S battery industry, and the trademark "555" the "Famous Trademark" in Guangzhou city as well as in Guangdong province. "555" brand R20S batteries have won National Excellent Quality Silver Award, while"555" brand LR6 alkaline batteries have won National Excellent Quality Gold Award. Moreover, "555" brand zinc-manganese alkaline batteries have been rewarded as "Chinese Top Brand Products" and "National Inspection Exemption Products".
Based on strengthening quality control and seeking development via technical progress, Tiger Head Battery Group Co., Ltd. Has been making persistent efforts to excel. As the first company using computer-controlled automatic discharging detection facility among the same business in China, the company has had a strict quality monitoring system in production. Thus for years running, the company has been evaluated as the "Advanced Enterprise of Quality and Profit" by the Ministry of Foreign Trade and Economic Cooperation, PRC, the State Bureau of Light Industry, and the Quality Control Association of Guangdong Province.
Since the year 1999, the company has been performing series of reforming with a capital outlay of RMB 400 million, introducing the most advanced production line of mercury free zinc-manganese alkaline battery, thus providing the consumers with environment friendly batteries of high performance. The company adopts in production the special explosion-proof structure, new material, new formula, new technique and the special sealing technology, all in the leading position in the world, which makes true the Mercury-free and Pollution-free in battery production fives years ahead of the national schedule. Recently, the company invested RMB 1.5 million independently developing the Real-time Monitoring Management System via IT new technology, which includes several parts of on-the-spot production management, operation instruction, and figures analysis, etc. This system, via visual image transformation and vivid industry control charts, can help monitoring persons to get accurate first-hand information about the production, even they are not on the production spot. Thus, it helps to improve management efficiency and reduce management cost. Today, a modernized Battery City has been set up in the new factory zone with the area of 170 thousand square meters.
