DC Worm Gear Motor for Machine (63ZYT125/63JW)

Name: DC Worm Gear Motor for Machine (63ZYT125/63JW)
Brand: all-electronics-online.com
SKU: 639889195
Availability: InStock
Rating: 4.7 (73 reviews)

Price:	US $ 90/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	63ZYT125/63JW
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Motor Diameter:	63mm,73mm. 80mm, 89mm etc
Motor Data:	Adjusted by Customer
Gear Material:	Plastic or Copper
Application:	Power Tools
Operating Speed:	Low Speed
Excitation Mode:	Compound
Structure And Working Principle:	Brush

Product Description

DC WORM GEAR MOTOR

We can provide many models worm gear motor. From 20w-1000w. And the motors can be used in auto door, lift system and other machine. We can design according to your speical requirement.

1. Fit for appliances that shaft from gearbox place 90° To the motor.
2. Motor speed can be adjusted according to customer's need.
3. Our motors can have encoder, brake, thermal protector, electromagnetic brake.
Motor Technical Data

Model	Rated Voltage (V)	Rated Current (A)	Single motor			Deceleration motor
Model	Rated Voltage (V)	Rated Current (A)	Torque (Nm)	Speed (rpm)	Power (W)	Torque (Nm)	Speed (rpm)	Power (W)
63ZYT12-40-1	12	5	130	3000±10%	40	2.3	83±10%	20
63ZYT12-85-1	12	11	240	3400±10%	85	4.3	94±10%	43
63ZYT24-40-1	24	2.5	130	3000±10%	40	2.3	83±10%	20
63ZYT24-85-1	24	5.5	240	3400±10%	85	4.3	94±10%	43
63ZYT-30-100-1	30	5	280	3000±10%	100	2.1	200±10%	50
63ZYT60-100-1	60	2.5	280	3000±10%	100	1	430±10%	50

The specifications can be designed according to the customer's requirement !

Ningbo Yinzhou Longway Technology Co., Ltd. is a professional motor, machinery and electronic products manufacturer in China. Since day one after its establishment, our company has spared no efforts in developing new products and optimizing them. A comprehensive and consistent quality system has been since long established, from design to production, form marketing to after sale service. Our company attaches great importance to employee training. It pays off when the quality of each and every one of our employees keeps improving. Now the motor products include PMDC motors, brushless motors, stepping motors, AC and DC gear motors, synchronous motors, brushless servo motors. Most of products are CE, UL approved. We can also complete OEM/ODM orders in accordance with clients' specific requirements, designs and samples.

The advanced technologies of design and manufacturing were adopted from Germany. We take pride in the CAD/cam mould tooling center and the testing center. We enjoy an excellent reputation in Europe, America, Australia, Middle East, and southeast Asia as well as in China.

"satisfactory products plus satisfactory services" makes our success happen. We sincerely hope to have and also thank for valuable supports and cooperation from all friends in the world.
