Deep Cycle AGM Battery with Long Life 12years 6V100ah CS6-100d

Prod Model:	CS6-100D
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	195*170*207*210mm
Voltage:	6V
Weight:	15.3kgs
Capacity:	100ah
Color:	Black / Dark Gray
Warranty:	3 Years
Expected Cycle Life:	10~12 Years
Delivery Time:	7 Days
Export Markets:	Global
Application:	UPS, Lighting, Electric Bicycle, Solar Product
Type:	Lead-Acid Batteries
Usage:	Boat
Nominal Voltage:	6V
Discharge Rate:	Low Discharge Rate
Rechargeable:	Chargeable
Shape:	Deep Cycle AGM Battery 6V100ah

Product Description

Deep Cycle AGM Battery with Long Life 12years 6V100ah
Model: Deep Cycle AGM Battery 6v100ah
Size: 195*170*207*210mm
Warranty: 3years
Delivery time: 15-20days
Certificates: CE, IEC, ISO
Market: Global


Deep Cycle AGM Battery with Long Life 12years 6V100ah
Company Introduction

CSPOWER BATTERY TECH Co., Ltd is a professional manufacturer and exporter of environmental friendly Rechargeable Deep Cycle AGM Sealed Lead Acid (SLA) Batteries, Solar GEL Batteries, OPzV Battery, Car/Auto Batteries, Motorcycle Batteries, Telecom Batteries, Lithium batteries and other Solar related products such as Solar inverter, Solar charger controller, Solar panel and so on.

Incorporated in 2003, CSPOWER has steadily expanded to approximately 1000 employees which include an experienced management team supported by a team of highly committed technical and manufacturing workers.


Deep Cycle AGM Battery with Long Life 12years 6V100ah
Characteristics

VRLA valve regulated sealed free maintenance lead acid battery 6V up to 300Ah.
Advanced Features:
1. Sealed and maintenance free operation
2. Non-Spillable construction design
3. Safety valve installation for explosion proof.
4. High quality and high reliability.
5. Exceptional deep discharge recovery performance.
6. Low self discharge characteristic.
7. Flexibility design for multiple install positions
8. The operating ambient temperature -40 to +65
9. Long life span 10-12years
10. Using oxygen recombination technology: Maintenance-free
11. Pb-Ca-Sn alloy for plate grids: Less gassing and less self-discharging
12. High quality AGM separator: Extend cycle life and prevents micro short circuit
13. ABS material: Increases the strength of battery container. (Flame-retardant ABS is optional)
14. High purity raw material: Ensures low self discharge rate
15. Silver-coated copper terminals, brass insert terminals and lead terminals improve the electric conductivity



Deep Cycle AGM Battery with Long Life 12years 6V100ah
Application

Engine starting, Communication equipment;
Fire & security systems;
Uninterruptible power supplies;
Telecommunication systems;
Electronic cash registers;
Electronic test equipment;
Processor based office machines;
Control equipment;
Electric powered bicycle and wheelchairs;
Geophysical equipment;
Marine equipment;
Medical equipment;
Portable cine & video lights;
Solar powered systems;
Television& video recorders;
Vending machines;
Alarm Systems, Computers;
Power Tools;
Emergency Lighting Systems;
Toys; Geophysical Equipment;
Vending Machines;
Other standby or primary power supplies.



Deep Cycle AGM Battery with Long Life 12years 6V100ah
OUR BATTERY MATERIAL ADVANTAGES:
1) Container/Cover: Made of UL94HB and UL 94-0ABS Plastic.
2) 99.99% pure new lead never use recycle lead.
3) Negative Plates: Use the special PbCa alloy grids, optimize the recombination efficiency and less gassing.
4) High quality AGM separator
5) Positive plates: PbCa grids minimize corrosion and prolong life.
6) Terminal post: Copper or lead material with maximum conductivity, enhance the high current rapidly.
7) Vent Valve: Allows the release of the excess gas automatically for safety.



Component	Positive Plates	Negative Plates	Separator	Safety Valve	Terminal	Cover	Lead
Raw Material	Lead Dioxide	Lead	Fiberglass	Rubber	Copper	ABS	Pure 99.99% Lead



Model NO.	Nominal Voltage (V)	Rated Capacity(AH) 10hrs/25ºC	Approx. Weight		Dimensions(mm)								Terminal Type
			kg	lbs	Length		Width		Height		Total Height
					mm	inch	mm	inch	mm	inch	mm	inch
CS6-2.8D	6	2.8	0.53	1.17	67	2.64	34	1.34	100	3.64	103	4.06	T1
CS6-1.3D	6	1.3	0.30	0.66	98	3.86	25	0.98	52	2.05	56	2.20	T0
CS6-3.3D	6	3.3	0.63	1.39	134	5.28	34	1.34	61	2.40	66	2.60	T0
CS6-3.5D	6	3.5	0.66	1.45	70	2.76	48	1.89	101	3.98	106	4.17	T1
CS6-4D	6	4	0.69	1.52	70	2.76	48	1.89	101	3.98	106	4.17	T1
CS6-4.2D	6	4.2	0.71	1.56	70	2.76	48	1.89	101	3.98	106	4.17	T1
CS6-4.5D	6	4.5	0.78	1.72	70	2.76	48	1.89	101	3.98	106	4.17	T1
CS6-5D	6	5	0.85	1.87	70	2.76	48	1.89	101	3.98	106	4.17	T1
CS6-6D	6	6	1.00	2.20	151	5.94	34	1.34	94	3.70	100	3.94	T1
CS6-7D	6	7	1.10	2.42	151	5.94	34	1.34	94	3.70	100	3.94	T1
CS6-8D	6	8	1.28	2.82	151	5.94	34	1.34	94	3.70	100	3.94	T1
CS6-10D	6	10	1.65	3.63	151	5.94	50	1.97	94	3.70	100	3.94	T1
CS6-100D	6	100	15.30	33.66	195	7.68	170	6.69	207	8.15	210	8.27	T16
CS6-14D	6	14	1.96	4.31	151	5.94	50	1.97	94	3.70	100	3.94	T1/T2
CS6-12D	6	12	1.81	3.98	151	5.94	50	1.97	94	3.70	100	3.94	T1
CS6-35D	6	35	10.20	22.44	196	7.70	131	5.16	155	6.10	180	7.09	T16
CS6-160D	6	160	25.00	55.00	307	12.09	170	6.69	220	866	225	8.86	T19
CS6-180D	6	180	29.00	63.80	260	10.24	180	7.09	246	9.69	250	9.84	T19
CS6-200D	6	200	30.50	67.10	322	12.68	178	7.01	227	8.94	230	9.06	T10
CS6-220D	6	220	31.50	69.30	322	12.68	178	7.01	226	8.90	251	9.88	T19
CS6-225D	6	225	31.50	69.30	322	12.68	178	7.01	226	8.90	251	9.88	T9
