Differential Pressure Transmitter (DPT-26)

Name: Differential Pressure Transmitter (DPT-26)
Brand: all-electronics-online.com
SKU: 677591176
Availability: InStock
Rating: 4.3 (87 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	DPT-26
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Power Supply:	24VDC
Medium:	Liquids, Gas or Steam
Display:	Digital
Function:	Electric Signal-Controlled
Accuracy:	0.1
Indicating Pressure Reference:	Gauge Pressure, Absolute Pressure
Application:	Industrial
Structure:	Bellows Pressure Gauge
Connection Type:	by Thread 1/4NPT
Measuring Range:	Differential Pressure

Product Description

Differential Pressure Transmitter (DPT)-26

Diffused silicon oil filled micro differential transmitters are consist of both isolation membrane differential pressure sensor and integrated circuit, which has characteristics of high precision, good stability, high reliability and good sensibility. When it is built-in microprocessor(MCU) which can correct nonlinearity and compensate temperature drift. Achieve accurate data transfer, local equipment diagnoses and long-distance bidirectional communication. It is ideal pressure transmitter for Various gas, liquid pressure measurement

Specification:

Pressure Range: 0-1Kpa -100Kpa; 0-6Kpa -7000kpa,
Accuracy: +/-0.1%; +/-0.2%; +/-0.5%
Power Supply 24VDC
Output: Two Wire: 4-20mA,
Working Temperature: -20oC-80oC
Long Stability: <= +/-0.2% F. S per year
Connection Size: G1/4(FM), 1/4npt(m)
Medium: Gas and liquid compatible with stainless steel(316LSS)
Over Load Pressure; 10 times of rated range
Explosion-proof is available

Beijing Huamai new technology Co., Ltd. Is a professional designer & manufacturer of instrumentation and automation meter since 1995, also a "high-tech enterprises" located in state-level industrial development zones, Certificate No: 0130273F. The company has developed the first generation of vortex flow meter, Engineer Han is the creator of this type flow meter. Under the leadership of Engineer Han (president), the company towards to bring products to promote application of engineering and technology mutual development.

Our Flow Meter Development History:

Release thermal-vortex flow meter in early of 70s, Release stress, large-diameter plug-in vortex flow meter in 80s, Release small-caliber, high temperature, corrosion-resistant, as well as two-wake vortex flow meter in 90s, Release Down hole ESP instrument in 2000. In recent years, due to the use of the latest microprocessor technology and modern digital signal processing, so that the vortex detection with a variety of intelligent functions which standard for the trend of vortex flow meter.

Main products are

Vortex Flow Meter, Vortex & Swirl Flowmeter;

Ultrasonic Flow Meter, Ultrasonic Level Meter,

Digital Pressure Gauge, Pressure Transmitter,

Intelligent Pressure Switch; Digital Flow Meter,

Downhole (Borehole ) Flow Meter, ESP downhole sensor and so on.

HMT. VFM series vortex flow meter due to its high quality and is widely used in aerospace, petrochemical, oil, metallurgy, mining, electrical, mechanical, construction, railways, environmental protection, gas, heat, running water, the flow distribution network measurement and automation. It is nominated the solo flow meter manufacturer by Tsinghua Tongfang Group for many years.

Our Products are widely application in Beijing and a number of national key projects, main projects are in China Central Television, the Central Party School, the People's Liberation Army 301 General Hospital, Shen hai heating network, heating network in Changchun, Beian power plant in Heilongjiang province, Power plant in Xiangfan, Hubei Province, Liaohe Oilfield, Daqing Oil Field, CNOOC (China national offshore oil corp) and so on, more than 100 units and projects.
