Differential Pressure Transmitter -DPT (DPT-26)

Name: Differential Pressure Transmitter -DPT (DPT-26)
Brand: all-electronics-online.com
SKU: 678232372
Availability: InStock
Rating: 4.6 (21 reviews)

Price:	Negotiable/Piece
Trade Terms:	others
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	DPT-26
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Range:	-100kpa ~ 40MPa
Power Supply:	24VDC
Medium:	Liquids, Gas or Steam
Display:	Digital
Function:	Electric Signal-Controlled
Accuracy:	0.1
Indicating Pressure Reference:	Gauge Pressure, Absolute Pressure
Application:	Industrial
Structure:	Bellows Pressure Gauge
Connection Type:	by Thread 1/2NPT or M20*1.5

Product Description

Differential Pressure Transmitter (DPT)

Feature:
1) High precision, high stability, can be used for measument of micro-gauge pressure, vacuum, level, density and flow
2) Two-wire system
3) Anti-vibration, strong
4) Range and zero point are adjustable, HART protocol is optional
5) Explosion-proof

Main technical parameters
Output signal: Two-wire 4~20mA DC (HART is optional).
Power supply: 12VDC~45VDC, Typical 24VDC.
Measuring range: -100KPa~40MPa (Range and zero point are adjustable)
Accuracy: 0.5%FS; 0.25%FS: 0.1%FS
Stability: 12 months not more than max error
Display format: LCD display.
Temperature effects: Max error <0.3% Max range/10° C
Pressure process connection: 1/2-14NPT
Damping: Electric damping is 0 ~ 16S
Explosion-proof: Intrinsic: IbIICT5 isolation-proof: DIICT4
Electric connection: M20*1.5
Vibration effects: 0.1%FS 10 to 55Hz S=0.15mm
Communication: Hart, RS485.
Operating temperature: -25° C~85° C
Ambient temperature: -25° C~80° C
Relative humidity: 5%~95%.

Beijing Huamai new technology Co., Ltd. Is a professional designer & manufacturer of instrumentation and automation meter since 1995, also a "high-tech enterprises" located in state-level industrial development zones, Certificate No: 0130273F. The company has developed the first generation of vortex flow meter, Engineer Han is the creator of this type flow meter. Under the leadership of Engineer Han (president), the company towards to bring products to promote application of engineering and technology mutual development.

Our Flow Meter Development History:

Release thermal-vortex flow meter in early of 70s, Release stress, large-diameter plug-in vortex flow meter in 80s, Release small-caliber, high temperature, corrosion-resistant, as well as two-wake vortex flow meter in 90s, Release Down hole ESP instrument in 2000. In recent years, due to the use of the latest microprocessor technology and modern digital signal processing, so that the vortex detection with a variety of intelligent functions which standard for the trend of vortex flow meter.

Main products are

Vortex Flow Meter, Vortex & Swirl Flowmeter;

Ultrasonic Flow Meter, Ultrasonic Level Meter,

Digital Pressure Gauge, Pressure Transmitter,

Intelligent Pressure Switch; Digital Flow Meter,

Downhole (Borehole ) Flow Meter, ESP downhole sensor and so on.

HMT. VFM series vortex flow meter due to its high quality and is widely used in aerospace, petrochemical, oil, metallurgy, mining, electrical, mechanical, construction, railways, environmental protection, gas, heat, running water, the flow distribution network measurement and automation. It is nominated the solo flow meter manufacturer by Tsinghua Tongfang Group for many years.

Our Products are widely application in Beijing and a number of national key projects, main projects are in China Central Television, the Central Party School, the People's Liberation Army 301 General Hospital, Shen hai heating network, heating network in Changchun, Beian power plant in Heilongjiang province, Power plant in Xiangfan, Hubei Province, Liaohe Oilfield, Daqing Oil Field, CNOOC (China national offshore oil corp) and so on, more than 100 units and projects.
