Digital 1 Wire Pressure Sensor with Display

Name: Digital 1 Wire Pressure Sensor with Display
Brand: all-electronics-online.com
SKU: 746788325
Availability: InStock
Rating: 4.5 (50 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	CX
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Price:	Competitive
Exported:	More 80 Countries
Quality:	World-Class
Experience:	More 20 Years
Warranty:	One Year

Product Description

Brief introduction of 3051(&1151) DP differential pressure transmitter
1. Widely used for measuring differential pressure (or pressure), level, density of liquid, gas or steam and convert the value of above into current signal output or digital protocol output.
2. The pressures are directly applied to the isolating diaphragm that provide isolation and resistance against process fluid corrosion.
3. Being microprocessor based, the electronic circuit is extremely versatile and accurate.
4. Combined with the sensor precision, it provides the high accuracy and range ability.
5. Transmitter performance is improved by continuous monitoring of the sensor temperature and corresponding corrections.
6. A local display permits easy reading and writing of data.

Medium	liquid, gas and steam
Measuring Range	0~0.1kPa to 0~40MPa
Output	4~20mA DC+HART protocol
Accuracy	±0.1%FS
Range and null point	Adjustable
Power Supply	12~45V DC, generally 24V DC
Protection	IP65
Storage Temperature	-40~+125°C
Overload Limit	150%-200% of rated range
Load Resistance	750Ω(See below diagram 1 for load characteristic )
Relative Humidity	5~95%
Converter housing	Low copper cast aluminum alloy with Polyurethane paint
Fill Fluid	Silicon / Fluorine Oil
Process Connections	1/2NPT, 1/4NPT
Static pressure	4, 10, 25, 32Mpa
Mounting	Directly supported by piping or optionally with mounting bracket for 2" pipes or with direct or remote seals. 3-way valve
Maximum positive shift	500% of minimum adjusting span
maximum negative shift	600% of minimum adjusting span
Material	Flange/Adaptor	Stainless Steel 316/Monel/ Haste alloy/Carton Steel
	Drains/Vents	Stainless Steel 316/Monel / Haste alloy
	Diagrams	Stainless Steel 316/Monel /Haste alloy C/ Tantalum
	Wetted O-Ring	Viton/ Buna-N
	Seal O-Ring	Viton/ Buna-N
	Bolts & Nuts	Carton Steel/Stainless Steel316

Cixi flowmeter Co., Ltd. Was established in 2008 and since then has been dedicating itself to research and manufacture of various kinds of flowmeter. With sophisticated experience in technology and management, CIXI Flowmeter has made a name for itself as an excellent manufacturer of various kinds of flowmeter. In 2007, we have especially set up Shanghai Cixi Instrument Co. Ltd for handling the deals of Export.

Thanks to outstanding performance of products, CIXI Flowmeters are being applied in more and more fields where there' S liquid to measure. CIXI Flowmeters have found users in many countries besides China, such as Malaysia, India, Thailand, Vietnam, South Africa and so on. Increasing number of users are finding that CIXI Flowmeter are kind of product with super performance and reasonable price.
