Digital Display 10000W DC-AC Pure Sine Wave Power Inverter

Digital Display 10000W DC-AC Pure Sine Wave Power Inverter
Price: Negotiable/Piece
Trade Terms: FOB,others
Min Order: 2/Piece
Pay Type: L/C,T/T,Western Union,Paypal
Prod Model: IG3110C 500-2000VA
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Product Name: Power Inverter
Capacity: 3000-5000va
Wave Form: Modified Sine Wave
Application: Home Appliances
Voltage Regulation: 220/230/240VAC± 2%
Voltagerange: 176VAC-280VAC(± 3VAC)
Nominal Frequency: 50/60Hz
Nominal Voltage: 220/230/240VAC
Display: LCD Display

Product Description

Digital Display 10000W Dc-Ac Pure Sine Wave Power Inverter

Key Features:
1. LCD Display
2. Full automatic and silent operation
3. Rack Tower design
4. High Frequency
5. Off mode charging
6. Compact size for convenient use and storage
7. Built-in 8AMP super charger for up to 100Ah battery
8. Small scale and cost effective inverter for home appliances and office equipment
9. Two - steps intelligent charging control to recharging time


Technical Specifications of LCD UPS Inverter IG3110C 500-2000VA
ModelIG 3110C 500-2000VA
500-121000-122000-241000-24
Capacity500VA/300W1000VA/600W2000VA/1200W1000VA/600W
Nominal voltage220/230/240VAC
Nominal frequency50/60Hz
Input
VoltageRange176VAC-280VAC(± 3VAC)
FrequencyRange50/60Hz
Output
Voltage Regulation220/230/240VAC± 2%
Frequency Regulation50/60Hz+0.1Hz
Wave FormModified sine wave
Switch timeStandard 2~4ms    Typical 6ms
Current
Charge Current10A10A10A6A
DC Voltage12V12V24V24V
Overcharge Protection15V15V30V30V
Display
LCDAC, battery, fault, etc
Operating Environment
Temperature0 º C~40º C
Humidity5%~95%(< 40º C, no condensation)
Storage Temperature

-25º C~55º C
Elevation Noise          (within 1 metre)Less than 1500 meter
< 45dB
Physical
Weight(KG)Net weight2.02.52.52.0
Gross weight2.22.72.72.2
Dimension: WXDXH mm224× 225× 80
