Digital Material Constantan Foil for Thermocouple

Name: Digital Material Constantan Foil for Thermocouple
Brand: all-electronics-online.com
SKU: 801297745
Availability: InStock
Rating: 5 (85 reviews)

Price:	US $ 20.5-30.5kg
Min Order:	50kg
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	K
Size:	0.5mm*4mm
Status:	Bright or Oxidized
MOQ:	30-50kg

Product Description

Digital material Constantan foil for thermocouple

TYPE K (CHROMEL vs ALUMEL ) is used in oxidizing, inert or dry reducing atmospheres. Exposure to vacuum limited to short time periods. Must be protected from sulfurous and marginally oxidizing atmospheres. Reliable and accurate at high temperatures.

1. Chemical Composition

Material	Chemical composition (%)
Material	Ni	Cr	Si	Mn	Al
KP(Chromel)	90	10
KN(Alumel)	97		3

2. Physical properties and Mechnical properties

Material	Density(g/cm3)	Melting pointºC)	Tensile Strength (Mpa)	Volume resistivity (μΩ.cm)	Elongation rate (%)
KP(Chromel)	8.5	1427	>490	70.6(20ºC)	>10
KN(Alumel)	8.6	1399	>390	29.4(20ºC)	>15

3. EMF Value range at different temperature

Material	EMF value Vs Pt(μV)
Material	100ºC	200ºC	300ºC	400ºC	500ºC	600ºC
KP(Chromel)	2816~2896	5938~6018	9298~9378	12729~12821	16156~16266	19532~19676
KN(Alumel)	1218~1262	2140~2180	2849~2893	3600~3644	4403~4463	5271~5331

Hangzhou Ualloy Material Co., Ltd is a high-tech enterprise which specialized in making all kinds of alloy strip such as high resistance alloy, low-resistance copper nickel alloy, precision alloy, FeCrAl alloy for exhaust purifier.

HangZhou Ualloy Material Co., Ltd have a full production line from melting, surface cleaning, rolling and slitting, full set of testing machine and can meet all kinds of technical requirement from customer. Our product is widely used in heating equipment, big steel mill, mineral, electrical equipment, food machinery, auto industry, aerospace industry. Our product not only is popular in domestic market, but also been exported to all over the world.

Our company aims to be the best-quality alloy strip producer in the world. We insist on developing the more advanced alloy strip technology, to serve all the customer, improve people's living level, make a more green earth in the future.
