DIN Rail Terminal Box Terminal Block Panel Board

DIN Rail Terminal Box Terminal Block Panel Board
Price: US $ 0.145-1.933/Piece
Trade Terms: FOB
Min Order: 100/Piece
Pay Type: L/C,T/T,Western Union
Prod Model: JN Series
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model Number: Jn Series DIN Rail
Material: Quality Steel and Al.Alloy

Product Description

*Professional Manufacturer of Din Rail
*CE / RoHS / ISO9001 Approved of Din Rail
*Small Order Accept

MOQ: 1000PCS

Din Rail 's small order is accept

FOB PRICE:
PORT: SHANGHAI or NINGBO

Payment Terms: L/C, T/T, Western Union, MoneyGram.

Supply Ability: 10000 Piece Day

If you need sample, we can supply for you.

Delivery Time: Within 25 days after receipt deposit.


Packaging Details:
Export Standard Packing or According to Customers' Requirement
MODEL SPECIFICATIONS WIDTH         (MM) HEIGHT    (MM) THICKNESS    (MM) LENGTH              (M) HOLE SIZE         (MM)
JN-701 TH35-7.5 35 7.5 1 1M/2M Φ5.2x15/Φ6.2x15
JN-702 TH35-6.5 35 6.5 1 1M/2M Φ5.2x15/Φ6.2x15
JN-703 TH35-15 35 15 1.5 1M/2M Φ5.2x15/Φ6.2x15
JN-704 TH15-5.5 15 5.5 1 1M/2M Φ4.2x12.2
JN-705 G32-15 32 15 1.2 1M/2M Φ6.2x15


MODEL SPECIFICATIONS WIDTH         (MM) HEIGHT    (MM) THICKNESS    (MM) LENGTH              (M) HOLE SIZE        (MM)
JN-706 TH35-7.5 35 7.5 1 1M/2M Φ4.8x25
JN-707 TH35-7.5L 35 7.5 1.5 1M/2M Φ5.2x15/Φ6.2x15
JN-708 G32-15L 32 15 1.5 1M/2M Φ6.2x15
JN-709 C25-10L 25 10 1.1 1M/2M Φ4.8x25
Our Yueqing Jianghong electrical appliance factory is a new style manufacturer whom focuses on the research and development of Miniature circuit breaker, terminal block and electric accessories in China. Our Products had exported to Middle East countries, South Asia, Africa USA, Europe, Africa and South America etc more than 20 countries by feedback good reputation. Jianghong found in year 2004, after several years ' improvement, from a small workshop developing to a team working includes design and research department, international department, financial department. One the way to the bright tomorrow, Jianghong Electrical which passed ISO9000 system are striving to put the quality as the basis of development, all our circuit breaker and terminal block are strict to according national and international standard. Most of them were approved by CE& RoHS certificate and all electric breaker compliance to IEC standard. Sincerely work with you to create a better tomorrow.
