DIN Rail Terminal Connector (UK series) UK Teminal Block UK6njd

Name: DIN Rail Terminal Connector (UK series) UK Teminal Block UK6njd
Brand: all-electronics-online.com
SKU: 826392525
Availability: InStock
Rating: 4.8 (124 reviews)

Price:	US $ 0.35/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	UK6JD
Application:	Cable
Environmental Protection:	General
Connection Mode:	In-Line Connector
Shape:	Rectangle
Contact Termination Form:	Screws Fixed

Product Description

General:

GSUK series combined terminal row adopts frame type screwconnection structure. The design complies with IEC60947-1, GB14048 standards, which is widely used in the circuit of AC 50Hz (60Hz), rated voltage 660V, DC 40V and below, rated sectional area 0.75~150mm² conncction conductor, it also is suitable for connecting the circle copper conductor of tube terminal that is not specially processed or pressure welding.

Characteristics:

1,Reasonable installation structure design, wide general-purpose nature, can be used both G type and TH type guide rail. If it is above 50mm, adopts fasten accessory installation.
2,Small volume, complete set of spccification, big connectcd conductor sectional area and good electrical conductivity, the one that is below 50mm adopts copper press line frame and copper fasten screw; and the one that is above 50mm, adopts copper press line frame and steel screw and copper skirt plate. It has big tighten moment and self-locking function.
3,The strong combined function makes the connection of conductor be simpler.

Explain:

(1)End covcr: Thickncss 1.5mm grey
(2)10 Center counection-strips, can be divided into 2 position or 3 position.
(3)Isolator bridge bar: 10-position, divisible need cushion block.
(4)Switch bar for 2 terminal blocks complete, add end cover between two teminals.
(5)Separating plate: be used for electrical separation of neighbouring brodges.
(6)Partition plate: 1.5mm Thickness
(7)Unviersal end fixed piece.

ITEM NO.	H(MM)	R(MM)	NAIL(MM)	PACKING
BS-4mm	5.3	4	1.7*15	100pcs
BS-5mm	6.5	5	1.7*15
BS-6mm	8.1	6	1.7*17
BS-7mm	8.7	7	1.8*19
BS-8mm	9.6	8	1.9*21
BS-9mm	10.7	9	2.0*22
BS-10mm	11.7	10	2.05*25
BS-12mm	12.8	12	2.05*27
BS-14mm	14.9	14	2.4*32
BS-16mm	16.9	16	2.5*35
BS-18mm	20.8	18	2.5*37
BS-20mm	23.6	20	2.8*42
BS-22mm	25.0	22	2.8*48
BS-25mm	27.7	25	3.2*48
BS-30mm	33.1	30	3.2*53
BS-35mm	36.6	35	3.2*58
BS-40mm	45.2	40	3.4*60
