Prod Model: |
MDC110A5000V |
Life: |
Over 1 Year |
Certificates: |
Ce, ISO9001:2008 |
Payment: |
T/T, L/C, Paypal |
Lead Time: |
15days |
MOQ: |
5PCS |
Manufacturing Technology: |
Optoelectronic Semiconductor |
Material: |
Compound Semiconductor |
Type: |
Intrinsic Semiconductor |
Package: |
Standard |
Application: |
Motor Control, Lighting Control |
Model: |
Mdc |
Brand: |
Mjer |
Product Description



Product Description:
AC/DC electric-machine'control
Various rectifying power supply
Lndustrial-heating controlling
Light-regulation
Non-touch switch
Soft-starters for electromotor
Static compensation of zero power
Electric welder
Frequency-transformer
UPS power
Charging and discharging of battery
BASIC. INFO
Mould no.:MTC1000A Material:Element Semiconducttor
Brand:SANSHE Type:Intrinsic Semiconductor
products Statu: in stock Prower semiconductor:Common Thyristor mould
Certificates: CE, ISO9001: 2000 CQC Warranty Period:15month
Export Maikets: Global Batch number:2014+
Packing:StandardCarton Standard:International
Origin:Zhejing, China ProductionCapacity:30000PCS/Month
Type table:
I TAV | V TM | VDRM VRRM | IDRM IRRM | I GT | VGT | Di/dt | ITSMS | ITRMS | Rjc | Tc |
A | V( ≤) | V | mA( ≤) | mA | V | V/μ s | A | 103A2S | ºC/w | ºC |
25 | 1.69 | 600-2000 | 8 | 20-100 | 0.6-1.8 | 50 | 41 | 0.55 | 0.950 | 100 |
40 | 1.60 | 600-2000 | 8 | 20-100 | 0.6-1.8 | 50 | 63 | 1.00 | 0.650 | 100 |
55 | 1.55 | 600-2000 | 8 | 20-100 | 0.6-1.8 | 50 | 78 | 1.25 | 0.530 | 100 |
70 | 1.48 | 600-2000 | 10 | 20-100 | 0.6-1.8 | 50 | 110 | 1.60 | 0.410 | 100 |
90 | 1.7 | 600-2000 | 10 | 20-100 | 0.6-1.8 | 100 | 141 | 2.00 | 0.280 | 100 |
110 | 1.69 | 600-2000 | 12 | 20-100 | 0.6-1.8 | 100 | 173 | 2.40 | 0.250 | 100 |
130 | 1.75 | 600-2000 | 20 | 20-100 | 0.6-1.8 | 100 | 212 | 3.80 | 0.200 | 100 |
135 | 1.96 | 1800-2500 | 25 | 20-100 | 0.6-1.8 | 100 | 212 | 3.80 | 0.200 | 100 |
160 | 1.70 | 600-2000 | 20 | 20-100 | 0.6-1.8 | 100 | 251 | 5.40 | 0.170 | 100 |
160 | 1.90 | 1800-2500 | 25 | 20-100 | 0.6-1.8 | 100 | 251 | 5.40 | 0.170 | 100 |
182 | 1.62 | 600-2000 | 25 | 20-100 | 0.6-1.8 | 100 | 286 | 5.80 | 0.160 | 100 |
182 | 1.80 | 1800-2500 | 30 | 20-100 | 0.6-1.8 | 100 | 286 | 5.80 | 0.160 | 100 |
200 | 1.65 | 600-2000 | 30 | 20-100 | 0.6-1.8 | 100 | 314 | 7.20 | 0.140 | 100 |
200 | 1.90 | 1800-2500 | 30 | 20-100 | 0.6-1.8 | 100 | 314 | 8.20 | 0.140 | 100 |
250 | 1.57 | 600-1600 | 30 | 20-100 | 0.6-1.8 | 100 | 393 | 8.50 | 0.120 | 100 |
250* | 1.73 | 1800-2500 | 30 | 20-100 | 0.6-1.8 | 100 | 393 | 8.50 | 0.120 | 100 |
300* | 1.58 | 600-2000 | 40 | 20-200 | 0.7-2.0 | 100 | 471 | 9.30 | 0.100 | 100 |
330 | 1.58 | 600-2000 | 40 | 20-200 | 0.7-2.0 | 100 | 500 | 9.40 | 0.100 | 100 |
350 | 1.45 | 600-2000 | 40 | 20-200 | 0.7-2.0 | 100 | 550 | 11.0 | 0.090 | 100 |
400* | 1.90 | 600-2000 | 40 | 20-200 | 0.7-2.0 | 100 | 628 | 13.0 | 0.110 | 100 |
500* | 1.90 | 600-2000 | 40 | 20-200 | 0.7-2.0 | 100 | 785 | 13.0 | 0.087 | 90 |
600* | 1.90 | 600-2000 | 40 | 20-200 | 0.7-2.0 | 100 | 942 | 13.0 | 0.073 | 90 |
800* | 1.95 | 600-2000 | 40 | 20-200 | 0.7-2.0 | 100 | 1256 | 13.0 | 0.054 | 90 |
1000* | 1.95 | 600-2000 | 40 | 20-200 | 0.7-2.0 | 100 | 1458 | 13.0 | 0.055 | 90 |
1500* | 2.00 | 600-2000 | 60 | 40-200 | 0.7-2.0 | 100 | 2100 | 14.0 | 0.060 | 85 |
2000* | 2.00 | 600-2000 | 70 | 40-200 | 0.7-2.0 | 100 | 2600 | 15.0 | 0.051 | 85 |
