| Prod Model: |
FD-11 |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Complex |
| Flame Retardant Properties: |
HB |
Product Description
Shenzhen FOUND PRINTED CIRCUIT BOARD Co., Ltd , an electronics manufacturing service provider and printed circuit board manufacturer, offers custom-designed electronics manufacturing and MID-sized OEMs and ODMs. A wide range of end markets that include PCBAs for Automotive, Communications, Computing, Consumer, Industrial, and Healthcare All these PCBAs are being exported to foreign markets, mainly to eastern Europe market. SHTL is dedicated to being a long-term PCBAs partner with our customers to achieve quality and cost optimization.
A professional PCB& PCBA design, product, sale manufacturer, established in 2010. Specially dedicate to Security, Industrial Automation, Medical, Household Appliance PCBA and Electrics products finished assembly. Currently with 100 workforce and covering 2, 000 square meters area, our products exported worldwide including North American, & South American, European Countries and Asia, etc.
PCB Technical standard:
PCB Item | Manufacture Capacity |
Layer Counts | 1--20L |
Base Material | FR4, High-TG FR4, CEM3, aluminum, High Frequency(Rogers, Taconic, Aron, PTFE, F4B) |
Material Thickness(mm) | 0.40, 0.60, 0.80, 1.00, 1.20, 1.50, 1.60, 2.0, 2.4, 3.2 |
Max board size(mm) | 1200X400mm |
Board Outline Tolerance | ±0.15mm |
Board Thickness | 0.4mm--3.2mm |
Thickness Tolerance | ±8% |
Minimum line/space | 0.1mm |
Min Annular Ring | 0.1mm |
SMD Pitch | 0.3mm |
Holes | |
Min Hole Size(mechanical) | 0.2mm |
Min Hole Size(laser hole) | 0.1mm |
Hole Size Tol (+/-) | PTH: ±0.075mm; NPTH: ±0.05mm |
Hole Position Tol | ±0.075mm |
Plating | |
HASL/LF HAL | 2.5um |
Immersion Gold | Nickel 3-7um Au: 1-5u'' |
Surface Finish | HAL, lead-free HAL, ENIG, Plated Gold, Immersion Gold, OSP |
Copper | |
Copper Weight | 0.5--6oz |
Color | |
Soldermask | Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue |
Silkscreen | White, Black, Blue, Yellow |
Acceptable File Format | Gerber file, Powerpcb, CAD, AUTOCAD, ORCAD, P-CAD, CAM-350, CAM2000 |
Certificate | ROSH, ISO9001, UL |
Our professional engineering team can put your project into production in a short time. Sample pictures and BOM are needed to make customized products. Also we can supply for the copy of the PCB and PCBA, so you just sent me the enquiry is ok, we can do what you need to do!
SMT and DIP EquipmentAdvanced SMT Equipment: * HITACHI Screen Printer
* FUJI NXT- & FUJI XPF-L Modules
Assembly Production Machines: * 2 automatic YAMAHA YS24 and YS12 SMT lines and 3 automatic MX400 and MX200 STM lines
* 2 DIP Dual wave soldering line
* 2 manual soldering production line
Capacity: * 180 million points per month
Component range: * 0201, 0402, 0603, 0805, 1206, 1608, 2125, 3216
* Fine Pitch QFP to 0.2mm
* BGA, Flip Chips, Connectors
* BGA to 0.2mm
Testing Equipment: * Printing Solder Paste Test
* AOI(Automatic Optical Inspection)
* X-ray for BGA and QFN Testing
* Function Testing
* In Circuit Testing
* Testing Service
Every board is carefully examined by our dedicated inspection team using AOI and high magnification viewers. Using our X-ray machine, we test PCBs to component level and all wiring is fully inspected and tested. Flash testing and earth bonding tests can also be undertaken where required.
Found PCB, established in 2005, Shenzhen Found Printed Circuit Board Co., Ltd. is part of Found group. Found PCB dedicated to provide one-stop service, to meet highest technology, quality and quick turn over challenges with lowest cost.
Shenzhen Found Circuit Board Co., Ltd supply all kinds of PCBs more than 10 years. Products including Rigid PCB (1-20 layers), flex PCB(1-4 layer), metal core PCB, Rigid-Flex PCB, especially in the metal core PCB, they use widly in the LED lighting.
A lot of comepays from Europe and North American buy from Found, cause we are the source, we can offer very good price, we think we can save a lot of your purchasing cost.
We also offer PCB solution. Such as Rigid-flex PCB, a lot of factories in China can not made this kind of the rigid-flex PCB. But Found is good at this...
With several year's rapid development, the production capability of our factory reachs 25, 000 square meters with over 500 employees and 180, 000 sq. M production area. Found PCB has been certified by International Quality System IS09001, ISO14001, TS16949 and UL (E361831).
We welcome the every opportunity to working for you. We have the good name in the PCB market.
