| Prod Model: |
DH |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Diameter: |
38mm (1.5inch) |
| Max Temperature: |
150º C |
| Length: |
610mm (24inch) |
| Output: |
RS232, RS485... |
| Sensor: |
Tube/Flange |
| Accuracy: |
±0.6-1% |
| Measuring Media: |
Liquids, Steam, Gases |
| Size: |
Dn10-50 |
| Measuring Principle: |
Electrical Principles |
| Type: |
Volume Type Flow Meter |
Product Description
Down Hole Flow Meter (Bore Hole Flow Meter); Downhole flow logger; Bore flow logger
Our down hole flow fluids logging also called down hole (bore hole ) flow logger, or electrical logging, it is a device for water wells to determine the aquifer and the salinity of water and water well water quality, such as water well water level, Fluid logging & Analysis in Real Time, Temperature logging & Analysis in Real time, Water level logging& Analysis in Real time, Electrical conductivity logging & Analysis in Real time
Downhole flow logger for Electric Submersible Pump which is also called borehole flow meter or downhole flow meter Which is widely used for oilfield or water well monitoring, besides flow, it Also include pressure and temperature sensor, if you need any other Request, please contactus for more discussion.
Downhole Flow Meter
Diameter: 1.5inch (38mm)
Length: 24inch (610mm)
Max operating temperature: 150ºC
Max operating pressure: 60Mpa (8700psi)
Application: Pressure Gradients, Production Tests, Build-up Pressure Tests, Injection Pressure Tests, Fluid logging & Analysis in Real Time, Temperature logging & Analysis in Real time, Water level logging& Analysis in Real time, Electrical conductivity logging & Analysis in Real time
Specification:
1)Diameter: 14mm; 25mm; 38mm^can be made as order
2)Nominal pressure: 40Mpa; 60Mpa; 80Mpa (5800PSI, 8700PSI, 11600PSI)
3)Medium: Liquids(water, polymer); Steam, air(single phase air)
4)Medium temperature: 0~80ºC; 0~125ºC; 0~150ºC; -40~+350ºC
5)Measurement depth: Underground 4000m; 6000m; 8000m
6)Environment temperature: Same to medium
7)Relativity: Immersed into the medium under pressure
8)Power supply: Memory type by battery; Read out type by cable
9)Output interface: RS232; RS485
10)Medium velocity: Liquids 0.5 to 9 m/s, air 5 to 70 m/s
11)Allow vibration acceleration: ≤ 1.0g
12)Flow range Ratio: 8: 1; 10: 1; 15: 1; 18: 1
13)Precision: 1%; 1.5%; 2.0%; 2.5%
14)Housing Material: 1Cr18Ni9Ti, 304, SS316, stainless steel, 174-4pH, can be made as order
15)Acquisition system: Hardware: IBM PC or compatibility PC: PIII800, 128M RAM and high; Operate System: Microsoft Window98, T, P or 2000 and higher
Beijing Huamai new technology Co., Ltd. Is a professional designer & manufacturer of instrumentation and automation meter since 1995, also a "high-tech enterprises" located in state-level industrial development zones, Certificate No: 0130273F. The company has developed the first generation of vortex flow meter, Engineer Han is the creator of this type flow meter. Under the leadership of Engineer Han (president), the company towards to bring products to promote application of engineering and technology mutual development.
Our Flow Meter Development History:
Release thermal-vortex flow meter in early of 70s, Release stress, large-diameter plug-in vortex flow meter in 80s, Release small-caliber, high temperature, corrosion-resistant, as well as two-wake vortex flow meter in 90s, Release Down hole ESP instrument in 2000. In recent years, due to the use of the latest microprocessor technology and modern digital signal processing, so that the vortex detection with a variety of intelligent functions which standard for the trend of vortex flow meter.
Main products are
Vortex Flow Meter, Vortex & Swirl Flowmeter;
Ultrasonic Flow Meter, Ultrasonic Level Meter,
Digital Pressure Gauge, Pressure Transmitter,
Intelligent Pressure Switch; Digital Flow Meter,
Downhole (Borehole ) Flow Meter, ESP downhole sensor and so on.
HMT. VFM series vortex flow meter due to its high quality and is widely used in aerospace, petrochemical, oil, metallurgy, mining, electrical, mechanical, construction, railways, environmental protection, gas, heat, running water, the flow distribution network measurement and automation. It is nominated the solo flow meter manufacturer by Tsinghua Tongfang Group for many years.
Our Products are widely application in Beijing and a number of national key projects, main projects are in China Central Television, the Central Party School, the People's Liberation Army 301 General Hospital, Shen hai heating network, heating network in Changchun, Beian power plant in Heilongjiang province, Power plant in Xiangfan, Hubei Province, Liaohe Oilfield, Daqing Oil Field, CNOOC (China national offshore oil corp) and so on, more than 100 units and projects.
