Dr-60-12 DIN Rail 60W 12V Switching Power Supply
| Price: |
US $ 5-10/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
DR-60-12 |
| Input Frequency: |
47~63Hz |
| Rated Current: |
4.5A |
| Rated Power: |
54W |
| Voltage Adj.Range: |
10.8 ~ 13.2V |
| Voltage Range: |
88 ~ 264VAC 124 ~ 370VDC |
| AC Current: |
1.2A/115VAC 0.8A/230VAC |
| Output Type: |
Single |
| Warranty: |
1 Year |
| Output Power: |
51 - 100W |
| Input Voltage: |
110-220V |
| Connection Mode: |
Series Switching Power Supply |
| Starting Mode: |
Self-excited Switching Power Supply |
| Voltage Regulating Mode: |
Frequency Modulation Type |
| Power Supplying System: |
Terminal Power Distribution Equipment |
| Certification: |
CSA |
| Brand: |
Yumo |
Product Description
DR-60-12 Din Rail 60w 12v Switching Power Supply
| MODEL | DR-60-5 | DR-60-12 | DR-60-15 | DR-60-24 |
| OUTPUT | DC VOLTAGE | 5V | 12V | 15V | 24V |
| RATED CURRENT | 6.5A | 4.5A | 4A | 2.5A |
| CURRENT RANGE | 0 ~ 6.5A | 0 ~ 4.5A | 0 ~4A | 0 ~ 2.5A |
| RATED POWER | 32.5W | 54W | 60W | 60W |
| RIPPLE & NOISE (max.) Note.2 | 80mVp-p | 120mVp-p | 120mVp-p | 150mVp-p |
| VOLTAGE ADJ.RANGE | 4.75 ~ 5.5V | 10.8 ~ 13.2V | 13.5 ~ 16.5V | 21.6 ~ 26.4V |
| VOLTAGE TOLERANCE Note.3 | ±2.0% | ±1.0% | ±1.0% | ±1.0% |
| LINE REGULATION | ±1.0% | ±1.0% | ±1.0% | ±1.0% |
| LOAD REGULATION | ±1.0% | ±1.0% | ±1.0% | ±1.0% |
| SETUP, RISE TIME | 100ms, 30ms/230VAC 200ms, 30ms/115VAC at full load |
| HOLD TIME(Typ.) | 100ms/230VAC 23ms/115VAC at full load |
| INPUT | VOLTAGE RANGE | 88 ~ 264VAC 124 ~ 370VDC |
| FREQUENCY RANGE | 47 ~ 63Hz |
| EFFICIENCY (Typ.) | 76% | 82% | 83% | 84% |
| AC CURRENT | 1.2A/115VAC 0.8A/230VAC |
| INRUSH CURRENT(max.) | COLD START 18A/115VAC 36A/230VAC |
| PROTECTION | OVERLOAD | 105 ~ 160% rated output power |
| Protection type: Constant current limiting, recovers automatically after fault condition is removed |
| OVER VOLTAGE | 5.75 ~ 6.75V | 13.8 ~ 16.2V | 17.25 ~ 20.25V | 27.6 ~ 32.4V |
| Protection type: Shut down o/p voltage, re-power on to recover |
| ENVIRONMENT | WORKING TEMP. | -20 ~ +60ºC |
| WORKING HUMIDITY | 20 ~ 90% RH non-condensing |
| STORAGE TEMP., HUMIDITY | -40 ~ +85ºC, 10 ~ 95% RH |
| TEMP. COEFFICIENT | ±0.03%/ºC (0 ~ 50ºC) |
| VIBRATION | 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes |
| SAFETY & EMC (Note 4) | SAFETY STANDARDS | Design refer to UL60950-1, TUV EN60950-1, EN50178 |
| WITHSTAND VOLTAGE | I/P-O/P: 3KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC |
| ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC |
| EMI CONDUCTION & RADIATION | Compliance to EN55022 (CISPR22) Class B |
| HARMONIC CURRENT | Compliance to EN61000-3-2,-3 |
| EMS IMMUNITY | Compliance to EN61000-4-2, 3, 4, 5; ENV50204, EN55024, Light industry level, criteria A |
| OTHERS | MTBF | 216.2K hrs min. MIL-HDBK-217F (25ºC) |
| DIMENSION | 78*93*56mm (L*W*H) |
| PACKING | 0.3Kg; 48pcs/15.4Kg/1.02CUFT |
