Dual Output Power Supply (D-200-2412)

Dual Output Power Supply (D-200-2412)
Price: Negotiable/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: T/T
Prod Model: BD-200-2412
Output Type: Dual
Output Power: 101 - 200W
Input Voltage: 110-220V
Warranty: >2 Years

Product Description

100% full load burn-in test
AC input: 110/220VAC± 20% selectable by switch
Protections: Short circuit/Overload
Low cost, high reliability
Size: 199*110*50mm
Specification                                                       BD-200-2412
DC output                     +24V  6A               +12V  4A
Wave and noise                    50mVp-p                 80mVp-p
Inlet stability                      ±0.5%                    ±1%
Load stability                      ±0.5%                    ±1%
Efficiency                        78%
Adjustable range for DC voltage                        ±10%
AC input voltage range  85-132VAC/170-264VAC  47-63Hz
AC Inrush current Cold-start current  15A/115V  30A/230V
OverLoad protection          105%-135% hiccup mode,auto-recovery
Over-Voltage protection     115%-140% rated output voltage
Setup,rise,hold up time 200ms,10ms,30ms at full load and 230VAC
Withstand voltage   I/P-O/P:3Kv    I/P-FG:1.5KV   O/P-FG:0.5KV   1minute
Isolation resistanc  I/P-O/P   IP/FG   OP-FG:500VDC/100M
Working temperature -10ºC_+50ºC
Safety Standards Design refer to GB4943,UL60950,EN60950
EMC Standards  Design refer to GB9254,EN55022 Class B
Weight 1.0Kg
Zhejiang Best Electric Co., Ltd. Founded in 2000. Our factory is located in Wenzhou Zhejiang.

With over 16 years of experience in design and manufacture of switching power supplies, we have established long-term relationship with hundreds of big customers in the field of industrial control, telecom, LED, display & lighting of buildings, elevator, laser equipment, TV & broadcasting, computer system, medical equipment, safety control, automotive system, banking equipment

The products include Single output series, Waterproof Series, Rainproof Series, DIN-Rail Series, With PFC Function Series, With Battery Charger Series, DC to DC series, Open Frame Series, Dual Output Series, Triple Output series, Quad Output Series, and custom-design switching power supplies, over 5, 000 models showing great flexibility.

The company is certified by SGS. Over 100 models power supply have acquired CE, RoHS approval, and more are underway. We have various advanced equipment, such as wave soldering and reflow soldering machine, AI component insertion machine, auto chip mounter, ATE, ICT, RoHS testing, environmental testing, EMC testing system, burn-in test room, data acquisition Only top brand international components are adopted for the key parts to ensure long lifetime and high reliability. Each unit is given full load burn-in test. With high quality and market reputation,

We were honored to become main SMPS supplier for Beijing Olympic Games, and Shanghai Expo 2010.

We are confident to offer you total power solutions and become our trustworthy power partner.
