Dynamic Microstrain Testing Strain Load Cell (B056)

Product Description

BRANS B056 strain transducer from HBM attaches directly to a plane surface with a friction joint and four bolts. This arrangement enables the strain of the test object to be transferred directly to the B056 making it ideal for installations where lack of space, or installation conditions, makes it difficult to use standard force transducers.

Ideal applications for the stainless steel B056 include multi-stand and C-stand presses. The strain transducer is mainly intended for applications where high forces are to be measured such as roll stands and injection molding machines.
Where bending effects need to be compensated, at least two B056 strain transducers should be mounted on opposite sides of the test piece and connected electrically in parallel.

Reliable measurement results
The strain sensor is designed with compensating elements for adapting to the different steel types commonly used in mechanical engineering. The feature means that the temperature effect that could lead to major zero offsets can be neglected. Without the compensating elements, the different thermal expansion coefficients of transducer and test object would change the transducer's zero signal.

This strain transducer features a high degree of protection and comes supplied with an oil-resistant cable. And it is easy integration into automation systems with digital amplifier system which could provide a self-sustained monitoring unit for all industry requirements.


6. Product Highlights:
For monitoring strain in statically and dynamically loaded units such as cranes, presses and roll stands
Simply bolted into place
Stainless steel
Protected from harmful environmental effects
Inexpensive
Strain gauge full bridge
