E33 5.8GHz 8CH/32CH Multiband Audio Transmitter&Receiver System Kit Tx&Rx for RC Fpv (TX5802+RC306)

Name: E33 5.8GHz 8CH/32CH Multiband Audio Transmitter&Receiver System Kit Tx&Rx for RC Fpv (TX5802+RC306)
Brand: all-electronics-online.com
SKU: 713147045
Availability: InStock
Rating: 5 (21 reviews)

Price:	US $ 48-60/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	TX5802+RC306
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model No.:	Tx5802+RC306
Channels:	32channels, Fatshrk Competible
Transmitting Distance:	2km in Open Area
Transmitting Power:	200mw/23dBm
Net Weight:	16g(Not Include Cable and Antenna)
Power Supply:	6-16 Volts
AV Input:	Analog AV Signal Input
Frequency Control:	Built-in Frequency and Phase Lock Loop
Size(Tx):	5727.212mm
Size(Rx):	755415mm

Product Description

E33 5.8ghz 8ch/32ch multiband audio transmitter&receiver system kit Tx&Rx for rc fpv(TX5802+RC306)

Features

5.8G 32ch transmitter
With channel button to change channels easily
Channel memory function for power-off
Very light and ultra mini size
The mini but powerful 5.8G 200mw transmitter would make your fly to 1-2 km away with only the stock antenna, advanced build-in regulator offers this transmitter very wide power input range.
Specificaitons of 5.8G 200mW AV wireless transmitter:
Transmitter frequency: 5645-5945MHz; 8CH
Transmitting Power: 200mW/23dBm
Transmitting distance: >2000m(open area)
Frequency control: Built-in frequency and phase lock loop
AV input: Analog AV signal input
ANT connector: SMA(inside the needle)
Power supply: 6-16 volts
Current supply: 200mA
Size: 57*27.2*12mm
Net weight: 16g(no cable and antenna)

Receiver(RC306):
Receiving frequency: 32CH
Receiving sensitivity: -90dBm
Frequency control: Built-in frequency and phase lock loop
Double lines AV output: Analog AV signal output
Antenna connector: SMA(Inside the needle)
Power supply voltage: 6-16V
Supply current: 100mA
Dimension: 75*54*15mm (aluminium alloy extrusion shell)
Remark: The receiver's power input is ranging from 8-12V, dual AV output is supported

Remark:
The transmitter's power input is ranging from 6-16V, however the voltage outptu from the TX for the camera us 0.5V, lower than the input power. It's suggested to use 3S lipo 11.1V battery.

Note: Antennas must be attched before powering on.
