Ee Type High Frequency Transformer (EI/EE/EFD/EP)

Name: Ee Type High Frequency Transformer (EI/EE/EFD/EP)
Brand: all-electronics-online.com
SKU: 696151545
Availability: InStock
Rating: 4.3 (79 reviews)

Price:	US $ 0.2-1/Piece
Trade Terms:	FOB
Min Order:	1000/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	EI/EE/EFD/EP
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Environmental Certification:	ISO14000
Quality Certification:	ISO9001: 2008
Safety Certification:	CQC03003095~3097
Other Certification:	RoHS
Coil Number:	Autotransformer
Coil Structure:	Toroidal
Type:	Transformer
Application:	Electronic
Phase:	Three
Certification:	RoHS
Usage:	High Frequency
Brand:	Liwang

Product Description

Specifications
Electric power transformer
*Low magnetic leakage, low loss
*Small distributed capacity
*Fine tuning inductance

Specifications
Switching power transformer:
1. Output power: 0.2W-2.5KW.
2. Rated current: 2A-1500A loads.
3. ISO9001, ISO1004., RoHS, UL, CQC

Switching power transformer Applications:

1. VCRS, Copy machine, Audio equipment, Game machines;
2. TV sets, Microcomputer equitpmen
3. Communications control equipment
4. Printers, Terminals.
5. Wigh good magnetic shield form itself and slight interferece.

Switching power transformer Electrical Characteristics:

1. Operating Temperature range: -20 to +45
2. TV sets, Microcomputer equipment
3. Switching frequency: 1kHz to 200kHz
4. Withstanding voltage: 1500/3750Vac for 1 minute between primary&secondary
5. Insulation resistance: 500Vdc 100M min. Between primar&secondary.

EE type transformer
Part No.	Terminal Pins	Dimension mm			Type	Electrical parameter
Part No.	Terminal Pins	A	B	C	Type	Inductance	Output power(W)
EE-8.3	6.0	8.0	8.0	8.3	V	100.0uH	0.2-3.0
EE-10	8.0	11.5	10.2	10.2	V	80.0uH	0.5-5.0
EE-13	10.0	12.0	12.5	13.0	V	120.0uH	0.5-8.0
EE-16-1	6.0	14.8	13.3	16.0	V	90.0uH	1.0-10.0
EEL-16	10.0	28.5	16.0	21.9	V	600.0uH	2.0-15.0
EE-19-1	8.0	17.6	16.0	19.0	V	800.0uH	3.0-30.0
EEL19	10.0	31.5	16.0	21.1	V	1200.0uH	3.0-30.0
EE-25-1	6.0	20.0	18.2	25.2	V	2000.0uH	3.0-45.0
EEL25	8.0	35.3	17.5	25.2	V	2800.0uH	3.0-45.0
EE-30	10.0	21.0	29.2	30.0	H	900.0uH	3.0-50.0
EE-40	14.0	27.6	30.5	40.0	H	1500.0uH	3.0-55.0
EE-42/15-1	12.0	33.8	44.0	42.0	H	2000.0uH	3.0-80.0
EE-42/20-1	12.0	45.0	39.8	42.0	V	1900.0uH	3.0-90.0
EE-55	20.0	50.0	50.0	55.0	H	3000.0uH	3.0-150.0
EE-65	16.0	55.2	51.8	65.0	H	4500.0uH	3.0-300.0
