Changan Group Co., Ltd. >> Ek Series Mini Circuit Breaker Ekm1-63 with Ce/CB Approved

Ek Series Mini Circuit Breaker Ekm1-63 with Ce/CB Approved

Ek Series Mini Circuit Breaker Ekm1-63 with Ce/CB Approved
Price: US $ 0.85-0.89/Piece
Min Order: 100/Piece
Pay Type: L/C,T/T,Western Union,Paypal,Money Gram
Prod Model: EKM1-63
Frequency: AC 50/60 Hz
Rated Voltage: 230/400V
Standard: GB10963/IEC60898
Parts: Cooper/Brass Parts
Contacts: Silver
Cover: Fire Proof
Service: OEM/ODM
Export Market: Global
Quality: AAA
Breaking Capacity: Low Voltage Circuit Breakers
Operation: Electric Type
Speed: Normal Type Circuit Breaker
Arc-extinguishing Medium: Air
Installation: Fixed
Structure: MCB
Certification: CB
Poles Number: 1p/2p/3p/4p

Product Description

Description For EKM1-63 MCB


ModelMINI CIRCUIT BREAKER
CodeEKM1-63
                                   Standard              IEC/EN 60898-1
Electrical
features
  Rated current inA1  2 3 4 6 10 16 20 25 32 40 50  63
  Poles               1P,1P+N, 2P, 3P,3P+N, 4P
  Rated voltage UeV                240/415
  Insulation coltage UiV                    500
  Rated frequencyHz                 50/60
  Rated breaking capacityA                6000/10000
  Rated impulse withstand voltage (1.2/50)UipmV                     4000
  Dielectric test voltage at and ind.Freq.for 1minKV                        2
  Pollution degree                         2
  Themo-magnetic release characteristic                B(3-5In) ,  C(5-10In) ,  D(10-20In)
Mechanical
features
  Electrical life                       8000
  Machanical life                      20000
  Contact position indicator                       Yes
  Protection degree                       IP 20
  Reference temperature of setting of thermal element°C                        30
  Ambient temperature(with daily average≤35°C)°C                     -5~+40
  Storage temperature°C                    -25…+70
Installation  Terminal connection type Cable/U-type busbar/Pin-type busbar
  Terminal size top/bottom for cablemm²                          25
AWG                        18-3
  Terminal size top/bottom for busbarmm²                          25
AWG                        18-3
  Tightening torqueN*m                         2.0
In-lbs.                          22
  Mounting 35mm DIN rail
  Connection   From top and bottom




Company Information


Our company is based on a electrics factory group which was established in the year of 1987,has been acknowledged as one of the most respected nation-wide manufacturers and exporters of low-voltage electrical apparatus in China mainland.

Comprising more than 62 factories, the group has more than 2500 employees and occupies 100,000 square meterworkshop during past 19 years

Now,we produce and export more than 5000 kinds of low voltage electrical applicances including all kinds of MINIATURE CIRCUIT BREAKER,MOULDED CASE CIRCUIT BREAKER,ELECTRICAL DISTRIBUTION BOX,CONTACTORS,RELAYS,FUSES,SWITCHED & METERS.

And most of our low-voltage electrical products passed certificates done by world-wide organizations, such as SEMKO,CB,KEMA,CE, RoHS, UL and ISO9001,these could prove the plentiful outcome. At the same time, our products have been chosen as "CHINESE FAMOUS BRAND PRODUCT"

Enquiry from both domestic and overseas customers are cordially welcome. Please feel free to tell us your requirements and let us do the best for you all the time.





Shipping:

1. Normally by SEA From NINGBO TO ...
2. Products are shipped via UPS / DHL / FedEx / TNT and so on expresses (door to door) If the amount is Small.
3. We Provide Drop shipping Service.
4. In order to ensure you receive your order tax free upon import, we can declare lower value according to your demand.
5. Shipping via EMS. UPS. FedEx and TNT express usually takes 3~7days dependent on the destination country.





Payment:

1. We usually use T/T (30% deposit before production and 70% to be paid against the copy of B/L).
2.If the Amount is small, you can pay to us by western union/Paypal/Money Gram.
3. L/C also acceptable






Warranty:

1. We provide 18 months warranty.
2. If the product is defective, please notify us within 10 days of delivery.
3. All products must be returned on their original condition, in order to qualify for a refund or exchange of goods





Our Services

A. Punctual delivery time:
We carry out your order into our well-organized production schedule, ensure your punctual delivery time.
Production report before your order packed.
Shipping notice and photos sent to you as soon as your order is shipped.

B. After-service:
We Pay high Attention To Your Feed back after receive the goods.
We Provide 18 months warranty after goods arrive.
We Positively Revert Your Complain Within 48hours.

C. Professional Sales:
We value every Inquiry Sent To Us, Ensure Quick Competitive Offer.
We Cooperate With Customer To Bid Tenders. Provide all Necessary Documents.
We Are A Sales Team, With All Technical Support From Engineer Team.






FAQ

Q 1. What's the payment term?
A. We accept tt,30% deposit and 70% balance against the copy of b/l.

Q 2. How's the delivery time?
A. Usually it will take about 25 days for production.

Q 3. Tell me the standard of package?
A. Normally are cartons, but also we can pack it according to your requirement.

Q 4. Could you offer form a? or c/o?
A. It's totally not a? problem. We can prepare relative documents to foreign affairs office or other office??to apply for this certificate.

Q 5. Would you accept to use our logo?
A. If you have good quantity, it absolute no problem to do oem.


Established in 1987, CHANGAN GROUP Co., Ltd. Has been acknowledged as one of the most respected nation-wide manufacturers and exporters of low-voltage electrical apparatus in P. R. China.

Comprising more than 62 factories with over 2500 employees and the whole corporation occupies 82000m2 ground during past 27 years.

We manufacture and export varieties of low voltage electrical appliance including all kinds of CIRCUIT BREAKER, CONTACTOR, RELAY, SWITCH, SOLAR INVERTER etc.

All of our production procedures strictly follow ISO9001, ISO14001 and OHSAS18001, most of our products are certified such as SEMKO, TUV, CB and CE which can prove our guarantee quality and our products also have been chosen as "Chinese FAMOUS BRAND PRODUCT".

We not only make efforts in developing our own products with "CHANA"brand but also provide OEM services. Hope to establish good business relationships with your esteemed company in near future.
