1. Overview
Circular cylindrical worm gear worm drive compared with the general contact line shape is conducive to the formation of hydrodynamicoil film. Low oil, anti-bonding ability, smooth, vibration, low noise, high transmission efficiency, good process performance,circular cylindrical worm gear is the country that promote the use of high-tech products, circular cylindrical worm reducer mechanicalCommission designated replacement products, has developed there GB9147 ~ 88 standardseries worm gear. Suitable working environment temperature -40 ºC ~ + 40 ºC oilinput speed is not greater than 1500 rev / min, the worm can be positive and negative direction.

 2. General Status:

Comparing with general worm transmission, Arc-column worm transmission's contact linc benefits to dynamic pressure oil mcmbranc' s generation. During operation, lower oil temperature, stonger anti-agglu-dination capacity, stablc work, less shake, lower norse, higher transmission efficiency, excellent proccss technology.  Mine, lifting, chemicals, light industry, construction ctc. It is substitute of the general speed redueers used for above in dustrics. The suitable work temperature is among-40ºCtill+40ºCinput speed is less than 1,500 rpm, worm could turn in forward and backward dircctions.Electric Fan Motor Micro Motor

 3. Installation, operation and maintenance of secd reducer:

a) Speed reducer should be installed on a stable place where it's convenient to fill or drain oil and good air circulation;

b) The original driver and working machine of speed reducer must be centralized, and the tolerance can't exceed acceptable data of coupler.

c) After installation the speed reducer could work flexible when turning by hand, no block.

d) After installation, speed reducer must have trial run without load before formal use, when the trial running successfully, then have trial with load as the following steps:

 . With 25% of designed loading;

  . With 50% of designed loading;

  . With 100% of designed loading;

When every step trial run, wait the temperature reach to the balance point, and no less than 2 hours; the highest oil temperature can' exceed 100ºC;speed reducer run stably; no shock or noisc; lubricate weel, all sealing points and contact surfaces have no lcak.

e) Preventive maintenance should be applied regularly, once any scratches or agglutinations were found, they must be climinated effeetively, All spare parts must be manufactured as standard to cnsure good quality, Renewed spare parts can,t be uscd until trial with load is executed.

 4. Storage condition

Electric Fan Motor Micro Motor

Speed reducer could be stored indoor for 30 days, fill up speed reducer with recommended lubrication oil, and use bolt to replace acrator. Turn around couple set worm once very 30 days in order to protect oil scaling and bearing. When working, lubrication oil depth should be reduced to the corrct position, and acrator be re-installed. If the speed reducer had been stored indoor over one year or need to be removed to outdoor, machine supplier company should be contacted, and ask for extra user's manual.

•   a) If there is no oil inside spced reducer, woum wheel oil of N320 must be filled to correct oil positi on level as regulation before running. Under special ease(if can't found oil of N320. N320 gear whecl oil be  permitted to use also), working load and transmission efficiency of speed reducer dccreasel.
•   b) N320 worm wheel oil and N320 gear wheel oil can't be mixed together.
•   c) Without permission, installed speed redueer can't be dismanted.

Electric Fan Motor Micro Motor
