| Prod Model: |
YJV |
| Size: |
Yjv |
| Application: |
Power Station |
| Voltage: |
Low and Medium Voltage Cable |
| Current: |
DC & AC |
| Insulation Material: |
XLPE |
| Certification: |
VDE |
| Brand: |
Jinshui |
Product Description
1 All Aluminum Alloy Conductor AAAC Conductor
Standard: ASTM B398, ASTM B399, BS 3242 DIN 48201, CSA C49, NFC 34-125
2 Applications & Advantages
Used as bare overhead conductor for primary and secondary distribution. Designed utilizing a highstrength aluminum alloy to achieve a high strength-to-weight ratio; affords better sag characteristics. Aluminum alloy gives AAAC higher resistance to corrosion than ACSR.
3 Specifications
AAAC bare conductor meets or exceeds the following ASTM specifications:
B-398 Aluminum Alloy 6201-T81 Wire for Electrical Purposes
B-399 Concentric-Lay-Stranded 6201 J81 Aluminum Alloy Conductors
4 Construction
Standard 6201-T81 high strength aluminum conductors, conforming to ASTM Specification B-399, are concentric-lay-stranded, similar in construction and appearance to 1350 grade aluminum conductors. Standard 6201 alloy conductors are similar to other alloy conductors commercially known as Ardival, Aldrey or Almelec. They were developed to fill the need for an economical conductor for overhead applications requiring higher strength than that obtainable with 1350 grade aluminum conductors, but without a steel core.
The DC resistance at 20"C of the 6201-T81 conductors and of the standard ACSR of the same diameter are approximately the same. Conductors of the 6201 J81 alloys are harder and, therefore, have a greater resistance to abrasion than conductors of 1350-H 19 grade aluminum.
5 CONDUCTOR TECHNICALS EXAMPLE
| CODE WORD | Size (KCM) |
Strand | Dia. ( Inches ) | Cross Section Area
( Sq.in) | Weight
Per 1000ft
( lbs )
| Rated Strength
( lbs )
| Resistance
Ohms/1000ft | Current Rating
( Amps ) |
Size | ACSR with Equiv. Diam. Stranding
( Al/St) | Approx.
ECCond.
With
Equiv.
Resistance | |
| Indiv. Wires | Complete
Cable | |
DC.@
20°C | AC@
75°C | |
| Akron | 30.58 | 7 | .0661 | .198 | .0240 | 28.7 | 1,110 | .659 | .785 | 107 | 6 | 6/1 | 6 | |
| Alton | 48.69 | 7 | .0834 | .250 | .0382 | 45.7 | 1,760 | .414 | .493 | 143 | 4 | 6/1 | 4 | |
| Ames | 77.47 | 7 | .1052 | .316 | .0608 | 72.7 | 2,800 | .260 | .310 | 191 | 2 | 6/1 | 2 | |
| Azusa | 123.3 | 7 | .1327 | .398 | .0968 | 115.7 | 4,460 | .163 | .195 | 256 | 1/0 | 6/1 | 1/0 | |
Established in 1984, Henan Jinshui Cable Group Co., Ltd. specializes in design and manufacture of various kinds of wires and cables. Our company's headquarters is located in Zhengzhou City of Henan Province, a famous city with convenient transportation in China.
Our company is in charge of 23 domestic sale companies and one trade company, Zhengzhou Jin Hang High-Tech Co., Ltd., mainly responsible for overseas market. There are 638 staff members in the factory, including 18 experienced engineers, 52 lab assistants and 568 workers. The capital asset reached USD10, 507, 000. We have various advance product lines and equipment, including 180 sets for producing use and 40 sets for testing and measurement use. Our product can perfectly meet requests of different standards, for example GB, IEC, BS and ASTM. We also have some ability to satisfy special need of customers. The annual product capacity of cables and wires of our factory is more than 10, 000, 000 kilometers.
As one of the leading manufacturers of cable industry in Henan Province, we obtained certificate of ISO9001 in 2003. All cables of colliery have gotten the certificate of safety for colliery. Our fire retardant cables are approved with the certification of proof products, and most of them met the standards of China Compulsory Certification (CCC). Moreover, we have been already licensed to enter the "Supplier of the China Government Procurement" by the government.
For years, we are keeping providing products with high quality and good service. Our cables and wires are widely used in the construction of buildings airports, power transportation, urban and rural power network reformation and other main projects. Both of products and the factory are greatly commended by customers. Also, we really highly value the overseas market. Our factory has the qualification to export independently which is awarded by Chinese government. The main products of our company have been exported to Africa, Australia, America, Italy, Singapore and other Asian countries. We insisted that pay adequate attention to every customer's request. We insist on our principle of "Good Quality Results Trust and Honesty Makes Success". We sincerely welcome you to touch with us and visit us.
