Electric-Railway Composite Link Insulator (FQX2-25)

Name: Electric-Railway Composite Link Insulator (FQX2-25)
Brand: all-electronics-online.com
SKU: 671060805
Availability: InStock
Rating: 4.8 (145 reviews)

Price:	US $ 1-100/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	50/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	FQX2-25
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Application:	High-voltage
Material:	Composite Polymer
Brand:	Ruily

Product Description

Company Introduction:

ZheJiang Ruili Electric Co., Ltd is an all-around advanced technology enterprise who is turning produce, develop and study together in the industry of high voltage of (power line, power station, locomotive) Composite Insulator, Zinc Oxide Surge Arrester, Fuse Cutout. And Isolateswitch.

Product Introduction:

The products are suitable for electric-railway of complex operation conditions,can effectively prevent flash accidents and decrease the times of clear and maintenance.Because of small volume,and when in the tunnel is clear, products of porcelain,glass insulator can not instead of it.

Main technical parameters:

Model	Rated Voltage	Rated mechanical bending load(kN)	Lightning impulse withstand voltage(peak)(kV)	P.F.withstand voltage(virtual value)(kV)	Min Creepage distance(mm)	Structure height H.(mm)
FQX1-25	25	60	270	130	1400	650
FQX2-25	25	60	270	130	1400	840
FQX3-25	25	60	270	130	1400	930
FQX4-25	25	60	270	130	1400	645
FQE1-25	25	60	270	130	1400	760
FQE2-25	25	60	270	130	1400	806
FQE3-25	25	60	270	130	1400	836
FQE4-25	25	60	270	130	1400	695

ZheJiang Ruili Electric Co., Ltd is an all-around advanced technology enterprise who is turning produce, develop and study together in the industry of high voltage of (power line, power station, locomotive) Composite Insulator, Zinc Oxide Surge Arrester, Fuse Cutout. And Isolateswitch.

Our company bases itself upon high starting-point, high quality, high Level., carries out ISO9001 Quality Management System comprehensively, have established complete Quality Quarantee System. Our company have advanced Researching and Developing, Testing, Produce machines and also have a strong engineering technology team which establishe the steady foundation of guaranteeing the quality of our products. The products of composite insulator, fuse cutout, zinc oxide surge arrester and isolate switch are test eligible by Quality Inspection and Testing Centre of Electric Equipment Ministry of Electric Power, P. R. Of China, and China National Centre for Quality Supervision and Test of Insulators and Surge Arresters.

And the products comform to international IEC61109, IEC60099-4, IEC600282-2, 291, 644, 787and national GB/T16927.1, GB/T8952 GB/T15166\15166.3 standards. Our products are widely sold domestic and abroad which export to South America, Africa, Middle East, Southeast Asia, etc.

Our company has complete sale, logistic, after-sales service and

Consultation system. Link with honest and credit, quality is first, satisfying

The requirement of cutomers is its own responsibility so as to make enterprise, society, workers harmoniously and uniformly.

"Ruili Electric" set up nice future with you together.
