Electrical Conductive Silicone Varnished Fiberglass Cloth

Prod Model:	MJ-2440
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	According to Customer Requirement
Sample:	Free
Customizable:	Yes
Application:	Generator & Transformerv
Type:	Insulation Tape
Chemistry:	Hybrid Insulation
Material:	Resin
Thermal Rating:	F 155
Maximum Voltage:	>100KV
Brand:	Mj

Product Description

Varnish Silicone Cloth 2440:
Appearance:
Surface smoothly without bubble and impurities

Features:
Excellent mechanical & electric property
Good heat & moisture resistance
Easy for procesance
Less thick tolerance

Application:
Used as liner insulation and coil insulation for the binding
Electric motor
Electric equipment's binding upInsulating materials for the electric motor, appliance. Etc


Packaging Detail: Diameter less than or equal to 200mm in each roll with moisture-resistance plastic bag outside, in carton with packing belt bandaged

Delivery Detail: 7-10 working days


Basic information
Product name	Polyester Varnished Glass Cloth
Item No.	MJ-2440
Brand	MJ
Material	Alkali free fiberglass cloth and silicone resin
Grade	Grade F
Technical Performance
Width	≥1000 mm
Thickness	0.1-0.25 mm
Tension Stress      10mm width                                    Endwise                                       Broadwise                                             45° direction                                 10% Extend (at 45° direction)	70(7.1)-120(12.2) N(kgf)                                                      40(4.1)-80(8.2) N(kgf)                                                        40(4.1)-80(8.2)N(kgf)                                                                    2-20(0.2-2.0) N(kgf)
Crack elongation rate                           Endwise                                        45° direction	1.5-3.0%                                                                                         15-20%
Edge tearing strength                     Endwise                                        45° direction	5(0.5)-25(2.6) N(kgf)                                                                50(5.1)-12-(12.2) N(kgf)
Breakdown voltage                           At room temperature                 180±2°C,2h                                   6% Extend (at 45° direction)               After damp	5-9                                                                                      2.5-4.5                                                                                 3-4.5                                                                                     2.5-4.5
Resistance to water (105±2° C, 24h)	Film no damage
Effect on oil (105±2° C, in #45 electric insulating oil 72h)	Oil PH ≤0.5mmKOH/g
Effect by oil (105±2° C, in #45 electric insulating oil 48h)	Film no damage

FAQ:

(1) Can you give me a discount price?

It is depending on the volume. The larger the volume is, the more discount you can enjoy.

(2) How can I get a sample?

Normally small samples (sizes not larger than 300*300mm) can be sent free of charge and customers just need to bear a little shipping charge, or you can provide your DHL, FEDEX, EMS, UPS courier account number to us. For bigger sizes, it depends.

(3) How can you deal with quality issues that customer feedback after receiving the goods?
1) Customers take photos of unqualified goods and then our sales staff will send them to Engineering Department to verify.
2) If the issue is confirmed, our sales staff will explain the root cause and take corrective actions in coming orders.
