Electrical Insulation Motorcycle Storage Battery Separator Sheet

Name: Electrical Insulation Motorcycle Storage Battery Separator Sheet
Brand: all-electronics-online.com
SKU: 762326005
Availability: InStock
Rating: 4.8 (78 reviews)

Price:	US $ 2.7/Ton
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Ton
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	FX19
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Product Name:	Motorcycle Storage Battery Separator
Dimension:	Customized
Sample:	Avaliable
Delivery:	One Week
Application:	Switch Baseplate
Type:	Insulation Paper
Chemistry:	Organic Insulation
Material:	Fiberglass
Thermal Rating:	250 250
Maximum Voltage:	20KV~100KV

Product Description

Motorcycle Storage Battery Separator, Lead Acid Battery Separator, Lithium Battery Separator, Gel Battery, VRLA Battery, PE Separator, Auto Battery, Motorcycle Battery

FX Group applies advanced technology to every customer's specific requirements. Each product must meet your unique specifications for uniformity, compression, pore size, absorption, and wicking properties. Our newly-invented AGM is a combination material that blends the best properties of microglass and the added strength of synthetic fiber. The separator has significantly higher puncture resistance that leads to a lower incidence of shorting in batteries. The fiberglass AGM battery separator is one kind of environmental-protection material which is made of micro glass fiber (Diameter of 0.6-6μm). It is white, innocuity, tastelessness and specially used in Value Regulated Lead-Acid batteries (VRLA batteries).

AGM Separator for Flooded/Vented Lead-Acid Storage Battery,This separator is made of fiberglass with 0.6-6um in diameter. It has advantages of good acid corrosion resistance, high stabil-ity, high porosity, small pore diameter and low internal resis-tance. It is ideal separator for value regulated sealed lead acid battery.

Thickness(mm): 0.4-5.0
Basic Weight(G/M. Mm): >=140
Resistance(Φ . Dm2): <0.0005

Thickness	mm	±5%d
Electrical Resistance	Ω.dm2	≤0.00050d
Tensile Strength	kN/m	≤2.0mm ≥2.0mm
Basic Weight	g/m2.mm	20Kpa
Max Pore Diameter	µm	≤20µm
Pressurzing Acid Absorption	%	≥550
Porosity	%	≥90
Acid-Wicking Height	mm/5min	≥90mm/5min

FX Group, as a high-tech enterprise which gathering the design creation, and production service in the fields of Fiberglass products like AGM Separator, Battery Separator, Composite Separator and the accessories of trucks like Roll Up Door, Aluminum Roller Shutter for Fire-fighting trucks, the ladders and some other accessories which was established in 2005 year and waslocated in Chuzhou city.

We had two plants with the total area of 40 thousand square meters, one plant was located in Chuzhou city and one plant was located in Changzhou city. The plant in Changzhou city major involved in the fiberglass products, the production capacity of our AGM battery separator which used in the VRLA battery arrive to 5000tons/year, we have total three production lines which imported from Japan, now our year exporting annual is about 5million USD per year, and the AGM battery separator was accepted and popular in India, Vietnam, Pakistan, Middle East and some other countries also. Our another plant which located in Chuzhou city major involved in the truck accessories, all the goods quality was making according to Europe standard, till now on we had been exported our truck roll up doors to Brazil, America, Iran, Dubai UAE, India and so on

FX has a great team that own leading and professional technique, standard management and perfect service. We have built long-term and steady business relationship with hundreds of customers all over the world.

We inherit our persistent in service strategy of quality at the first priority and clients at the uppermost.

We will prvide more relaable products and offer the better, safety. And efficientcy services for you.

We are sincerely looking forward to cooperating and communicating with you.

Choose FX, Choose The Best!
