Electrical Self Adhesive PVC Insulation Tape

Name: Electrical Self Adhesive PVC Insulation Tape
Brand: all-electronics-online.com
SKU: 665140875
Availability: InStock
Rating: 4.4 (114 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	CE
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Thickness:	0.125mm~0.2mm
Type:	Insulation Tape
Chemistry:	Hybrid Insulation
Thermal Rating:	H 180
Application:	Electrical Insulation Tape
Material:	PVC
Maximum Voltage:	600V
Color:	Red, Blue, Yellow,Green, etc
Brand:	Cowinelec, OEM,ODM

Product Description

PVC adhesive tape is made by smearing rubber like pressure-sensitive adhesive on PVC film (its backing material )and mangling them ,it has the feathers of insulation ,fire-resistance,high-voltage- resistance and cold resistance. It can be used in many electronic spare parts,automobile wires, winding wires and insulation protection.

Other size avaliable, welcome inquiry with us.

Code	Backing	Adhesive	Thickness (mm)	Adhesion (N/cm)	Tensile (N/cm)	Elongation (%)	Temperature (°C)	Voltage Breakdown (KV/mm)


100D	PVC	rubber	0.1	1.5	14	160	80	≥40
110D	PVC	rubber	0.11	1.5	15	160	80	≥40
130D	PVC	rubber	0.13	1.5	17	160	80	≥40
150D	PVC	rubber	0.15	1.5	22	200	80	≥40
165D	PVC	rubber	0.165	1.5	25	200	80	≥40
180D	PVC	rubber	0.18	1.5	28	200	80	≥40
190D	PVC	rubber	0.19	1.5	28	200	80	≥40
200D	PVC	rubber	0.2	1.5	30	220	80	≥40
100Z	PVC	rubber	0.1	1.5	14	160	80	≥40
110Z	PVC	rubber	0.11	1.5	15	160	80	≥40
130Z	PVC	rubber	0.13	1.5	17	160	80	≥40
150Z	PVC	rubber	0.15	1.5	22	200	80	≥40
165Z	PVC	rubber	0.165	1.5	25	200	80	≥40
180Z	PVC	rubber	0.18	1.5	28	200	80	≥40
190Z	PVC	rubber	0.19	1.5	28	200	80	≥40
200Z	PVC	rubber	0.2	1.5	30	220	80	≥40

PROFESSOINAL: High Voltage Electrical Materials and Poleline Hardwares

Cowin Electrical Co., Ltd, is located in the largest manufacturing base of low-voltage electric equipment of Liushi China, which is called "the Electric Device Metropolis of China".

Cowin regards quality of products as life. We have standard Management System. We produce and widely sell over 300 series, more than 10000 types in high-and-low voltage electrical device, complete equipment, power transformer, cable and wire, instrument and meter, welding equipment, which are praised by all users. A number of new independent intellectual property right, intelligent appliances is moving into the market.

We are keeping our business principles for "Approaching the first-class management, producing the first-class products, providing the first-class service". All Cowin staffs are working hard and constantly innovate.

Honest Cowin are welcome to all users to fighting a better tomorrow hand in hand, Cowin -Cooperation and doulbe win.

www.powerfitting.net; www.cowinelec.com
