Electrical Wire with Solid Copper Conductor PVC XLPE Insulated

Name: Electrical Wire with Solid Copper Conductor PVC XLPE Insulated
Brand: all-electronics-online.com
SKU: 753676005
Availability: InStock
Rating: 4.9 (47 reviews)

Price:	US $ 0.1-20/Meter
Trade Terms:	FOB,CFR,EXW
Min Order:	500/Meter
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	SHUA0089
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color:	as Your Requirement
Type:	Insulated
Conductor Type:	Solid
Conductor Material:	Copper
Insulation Material:	XLPE
Certification:	CCC
Brand:	Shenhua

Product Description

1)Use for electric wiring
2)PVC single core cable
3)High pure rigid copper
4)Low price good quality
5)China BV series

The cable is manufactured according to GB5023-2008 and JB8734-1998 national standard
Or international standard of 60227IEC.

Application
The cables can be applied to the copper(aluminum)-core cables in the rated A/C voltage of
U/U450/750V and the below power, lighting, daily electric appliances, apparatus and
Telecommunication equipments.

Operation characteristics
1-U0/U is 450/750V and 300/500V;
2-The allowed long-term working temperature of wire should not exceed 70° C;
The cable (wire) shall be installed at temperature not lower than 0° C;
3-The bending radius shall not be less than 4D of the cable overall diameter it is less
25mm; The bending radius shall not be less than 6D of cable overall diameter when it
Is more than25mm.

Manufacture length
1-The coil length of cable (wire) shall be 100M, filled reel length shall be more than 1000M;
2-The short cable are permitted with a length not less than 10m for each and their quantity
Shall not exceed 10% of the total supply length, and short length quantity of every piece
Not more than 2PCS;
3-Any supply length is permitted based on the agreement with buyer. The error of metering
Shall not exceed ± 0.5%.
