Electronic Components Transistor of Mosfet N-Channel Metal Oxide

Name: Electronic Components Transistor of Mosfet N-Channel Metal Oxide
Brand: all-electronics-online.com
SKU: 804192735
Availability: InStock
Rating: 4.4 (90 reviews)

Price:	US $ 1.28/Piece
Min Order:	25/Piece
Pay Type:	L/C,T/T,D/P,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	SIHG20N50C-E3

Product Description

FEATURES
• Halogen-free According to IEC 61249-2-21
Definition
• Low Figure-of-Merit Ron x Qg
• 100 % Avalanche Tested
• High Peak Current Capability
• dV/dt Ruggedness
• Improved Trr/Qrr
• Improved Gate Charge
• High Power Dissipations Capability
• Compliant to RoHS Directive 2002/95/EC

Category	Discrete Semiconductor Products
Family	Transistors - FETs, MOSFETs - Single
Manufacturer	Vishay Siliconix
Packaging	Bulk
Part Status	Active
FET Type	MOSFET N-Channel, Metal Oxide
FET Feature	Standard
Drain to Source Voltage (Vdss)	500V
Current - Continuous Drain (Id) @ 25C	20A (Tc)
Rds On (Max) @ Id, Vgs	270 mOhm @ 10A, 10V
Vgs(th) (Max) @ Id	5V @ 250A
Gate Charge (Qg) @ Vgs	76nC @ 10V
Input Capacitance (Ciss) @ Vds	2942pF @ 25V
Power - Max	250W
Operating Temperature	-55C ~ 150C (TJ)
Mounting Type	Through Hole
Package / Case	TO-247-3
Supplier Device Package	TO-247AC
