| Prod Model: |
FS-M-PS022 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Principle: |
Eddy Current |
| Max Switching Current: |
0.5A |
| Max Carry Current: |
1A |
| Max Contact Resistance: |
100mΩ |
| Max Load Power: |
10W |
Product Description
We are first class retailer, wholesaler, and exporter for Piston Type Flow Switch FS-M-PS022 in China since 2009. Quick response, fast delivery.
Principle:
Flow switch is the presence or absence of flow through the output switch control signal to the water sensor switch, the main switch signal. Divided into specific types normally open and normally closed type, in the main water control work flow monitoring role to play. Water flow switch and relay use with the usual components of the water control system, easy to use, no power is the flow switch on.
Application:
Mainly used for water heater, boiler, water dispensers, coffee machines, hot card machines, steam equipment, water system, the campus card sales, selling self-help water systems, water treatment equipment, cooling systems, mechanical equipment, instrumentation, pharmaceutical equipment.
Installation:
1, flow switch installation environment to avoid strong vibration, and shaking with the local magnetic environment, in order to avoid the flow switch malfunction. In order to avoid particles, debris into the water flow switch must be installed in the inlet filter.
2, when the magnetic material close to the water flow switch, its characteristics may change.
3, flow switches, relays must be compatible with use, as less power reed switch (typically 10W and 70W) easy to burn. Relay maximum power 3W, 3W power will be greater than the normally open and normally closed phenomenon.
Routine Maintenance:
Periodically clear the guide rod and float on the dirt (as the media cycle may be). Check for the loose buckle.
Technical Parameter:
| Items Parameter | Unit | Remarks |
| Max Switching Current | 0.5 | A |
| Max Carry Current | 1 | A |
| Max Contact Resistance | 100 | MΩ |
| Max Load Power | 10 | W |
| Max Switching Voltage | 100 | VDC |
| Max Broken down Voltage | 220 | VDC |
| Starting Flow | ≤1.5 | L/min |
| Working Flow Rating | 1.5-30 | L/min |
| Starting Water Pressure | ≤0.1 | Mpa |
| Min Withstand Water Pressure | ≤1.2 | Mpa |
| Max Withstand Water Pressure | 1.6 | Mpa |
| Working Condition Temperature | -10-80 | °C |
| Operating Temperature | -20-85 | °C |
| Working Life | 108 | 5VDC 10mA |
| Response Time | 0.2 | S |
| Release Time | 0.2 | S |
Bingo Industrial and Trading Company started to run businiess since 2006, which is located in Wenzhou Yueqing ---- The world-famous city for low-voltage electric apparatus.
We owns followed two subsidiary corporations:
Bingo sensor Technology Co., Ltd. ----- concentrates on pressure, level and flow control product.
Yueqing tongfa electronic Co., Ltd. ----- is engaged in electronic&electrical product, security product.
After several years development, Bingo now becomes a professional supplier for
* Pressure, level and flow control product applied to:
Water supply system
HVAC
Household appliances (refrigerator, Furnace, heater, dish-washing machine,
Water dispenser, food waste disposer and so on)
Steam control system
Vehicle
Oil transporting system
Medical equipment
* Security product
Warning light
Roadway safety
Mining safety
Alarm sire
* Electronic&Electrical product
Tact switch
Micro switch
Toggle switch
Foot switch
Earphone jacket
Industrial plug&socket
With many years' business accumulation and good cooperation with more than 150 companies, we are capable to offer our clients products with the competitive prices, satisfied quality and excellent services. Part of our products own CE, UL, TUV certificate.
At present, Bingo Industrial and Trading Company has 50-60 employees. We have set up business relationships with customers from more than 50 countries and regions. Through running business honestly, we earned the reputation from both local government and oversea clients.
We strongly insist on the principle of "quick response, the best service, satisfactory quality, and competitive price", and sincerely hope that every customer around the world would have the feeling of "Bingo" after the first business cooperation with us.
Looking forward to a win-win relationship with you!
