Elegent Design and UL Safe Approved Fuse

Name: Elegent Design and UL Safe Approved Fuse
Brand: all-electronics-online.com
SKU: 694461055
Availability: InStock
Rating: 4.8 (105 reviews)

Price:	US $ 0.01-1/Piece
Trade Terms:	FOB
Min Order:	1000/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	LGA
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Environmental Certification:	High Stability Electric
Quality Certification:	High Heat Exchanged Ceramic
Material Of Film:	0.125W~10W
Material Of Core:	1% 2% 5% 10%
Operating Temperature:	55° C~+70° C
Safety Certification:	CQC 03003095~3097
Other Certification:	RoHS
Breaking Capacity:	High
Usaga:	Electronic
Type:	Fuse Resistor

Product Description

Fuse
1. High heat exchanged ceramic core
2. High stability electric conduction film
3. RoHS & ISO9001

Fuse
Features:
1. Compact design, small and lightweight
2. Contribute to high Q and self-resonant frequencies
3. Coating: Epoxy resin ensures humidity resistance for long life
4. Taping type is convenient for automatic equipment
5. Size: 0204 to 0510
6. Inductance: 0.1uH to 39mH

Breaking capacity
Ratings:
160mA~5A: 50A 125V AC/DC
6.3A: 63A 125V AC/DC

Function characteristics:

recentage of rated current	blow time limit
100%	4 hours min
150%	1 hours min
200%	2 minutes max
400%	150ms min 10s max

Environmental specifications:
Operating temperature: -5 to 60 degrees Celsius
Stock conditions:

Temperature: +10 to 60 degrees Celsius
Relative humidity less than or equal to 75% storing for three years on average
Without dew, maximum value for 30 days, 95%
Structure:

Body: plastic (quantity = 1)
Termination: tinned copper wire (quantity = 2)
Weight: 0.26g (approximately) per fuse

Standards and approvals:
C-UL/VDE/CCC/PSE approved
See nominal melting I2t A2sec

Changzhou Southern Electronic Element Factory Co., Ltd. is located in China, with a long history. We enjoy convenient transportation by highway, railway and airway. It takes only one and half hours' Drive to Shanghai or Nanjing.

Our company was founded in 1989, and currently we employ more than 300 people, including 60 professional technicians, covering an area of 10, 000 square meters, with a construction area of more than 5000 square meters. Our main products are wirewound resistors, wirewound resistor fuses, membrane fuse resistors, fixed inductors, filters, ferrite transformers, ring-shaped coils, fuse dedicated energy-saving lamps and UL fuses. Our annual output is 200 million resistors, 200 million transformers, 100 million coils and 200 million fuses, which are mainly used for household appliances, communication equipment, energy-saving lamps, automation control devices (such as inverters), power equipment and facilities. Our products are exported to Europe, the United States and Southeast Asia. GE, OSRAM and PHILIPS are our customers.

Factory' S quality policy: "product quality, service in advance, customer satisfaction".

Environmental policy: "to comply with laws and regulations, pollution prevention, environmental awareness, continuous improvement of the environment
