| Prod Model: |
TK104 |
| Warranty Time: |
1 Year |
| Certificate: |
Ce FCC |
| Features: |
Internal Antenna, Waterproof, Magnetic |
| Delivery Time: |
1-3 Working Days |
| Quad Band: |
850/900/1800/1900 MHz |
| Network: |
GSM GPRS/GPS |
| Person Vehicle Security: |
Sos, Real Time Tracking, Geo Fence Alarms etc |
| OEM: |
Support |
| GPS Accuracy: |
5m |
| Power: |
12V-24V |
| Type: |
GPS Tracker |
| Use: |
Automotive&Hand Held |
| Carrier Frequency: |
Dual-Frequency |
| Operating Principle: |
GPS Satellite Positioning and Data Transmit by GSM |
| Port Number: |
20 |
| Model: |
GPS104 Tracker |
| Screen Size: |
No Screen GPS Tracker |
| Chip: |
No |
| Brand: |
Coban |
| Certification: |
ISO9001 Ce FCC |
Product Description
Emergency alarm safety car GPS Tracker system with free tracking software GPS-104B tracking unit is a device that uses the Global Positioning System (GPS) to determine the precise location of a vehicle to which it is attached and to record the position of the vehicle at regular intervals. The recorded location data can be stored within the tracking unit, or it can be transmitted to a central location database, or internet-connected computer, using a cellular (GPRS or SMS) or satellite modem embedded in the unit. This allows the vehicles location to be displayed against a map backdrop either in real time or when analyzing the track.
Advantages:
A)Built-in GSM/GPRS antennas
B)Built-in Microphone
C)Powerful magnet+waterproof
D)GPS+LBS double tracking solution
E)Absolute street address
F)Tracking By SMS or computer
G)Real-time online tracker
Features:
1. Small size GPS tracker, easy to take to everywhere
2. Powerful magnet+water proof, easy to adsorb in the hidden place of car.
3. Real-time tracking, retrieve of lost vehicles, cargo.
4. Tracking by SMS as well as with internet or PC
5. Protect children, old people or pets by remote control
6. Auto tack and can get location in real street/address name
7. Full battery can standby 80 hours and only need charge about 3-5 hours a time
8. Support both GPS / GSM station positioning ways.
9. Support SMS / GPRS dual-mode switching
10. with its compact and small size, (cigarette box size), easy hide and installation inside the vehicle.
Basic functions:
1. GPS + LBS double solution,exact street address
2. Auto track continuously
- Track with limited times upon time interval
- Track with unlimited times upon time interval
- smart track upon time and distance interval
3.Turning points update automatically
4.GPS drift suppression
5.Data logging or load
6.Alarms
7.Sleep Mode
8. Real time tracking via SMS or GPRS (TCP/UDP)
9.Track on demand by calling or sms comamnd
10. Live http google map link in message
11.Five authorized phone numbers
12. Voice Surveillance
13.Easy switch for track or Monitor
New Functions:
14.ACC work and alarm
15.Cut off the Oil and Power,Engine stop and resume
16.INT/EXT GSM/GPS antenna switch
18.Magnet battery
Specifications
Content | |
| Dim. | 94mm*60mm*38mm |
| Weight | 300g |
| Network | GSM/GPRS |
| Band | 850/900/1800/1900Mhz |
| GPS chip | SIRF3 chip |
| GPS sensitivity | -159dBm |
| GPS accuracy | 5m |
| Time To First Fix | Cold status 45s
Warm status 35s
Hot status 1s |
| Car charger | 12- 24V input
5V output |
| Wall charger | 110--220V input
5V output |
| Battery | Chargeable changeable 3.7V 800mAh Li-ion battery |
| Standby | 80hours |
| Storage Temp. | -40° C to +85° C |
| Operation Temp. | -20° C to +55° C |
| Humidity | 5%--95% non-condensing |
Application
Used widely for vehicle and other moving objects tracking. Real-Time Vehicle Tracking Solutions For Business
1)Live Fleet Tracking Systems: Engineered and tested to meet the most stringent fleet management applications, our GPS locators allow businesses to view company vehicles in real-time while also giving fleet managers lifetime access to historical GPS tracking data! Providing comprehensive reports that break down mileage driven, speeds driven, travel direction, start/stop data and more, users can easily manage a small or large number of company vehicles all through our user-friendly, online mapping system.
2)Boost Employee & Vehicle Efficiency: By utilizing a fleet management plan that calls upon GPS tracking devices, businesses large or small with company vehicles can evaluate employee driving activity, accurately document mileage and eliminate driving behaviors such as excessive vehicle idling that can hurt automotive maintenance, customer service and company profit.
3)Auto Theft Security: Vehicle locator systems can protect all of your companies mobile assets. Easy to set geo-fences will allow businesses to create safe zones that will send text message notifications if a vehicle moves outside the programmed safety zones. Don't let your business operations be slowed down by theft! With GPS trackers securing your company vehicles, automobile theft will be a thing of the past!
