Energy Saving Mica Band Heater

Prod Model:	energy saving mica band heater
Dimension(L*W*H:	Custom Size
Warranty:	1 Year
After-Sales Service Provided:	Overseas Third-Party Support Available
Insulation Material:	Mica
Resistance:	Cr20ni80 Resistance
Diameter:	Customized
Height:	Customized
Thermocouple:	with or Without
Connection:	Wire/Ceramic Connection /Connection Box

Product Description

Stainless steel mica heater is made of high quality nickel chrome heating wire as the Heating element,using natural mica as insulating layer ,high quality stainless steel as conduction heat

layer in the outside , we can according to your requirement to custom heater band , heater

plate and kinds of special shape products.
 .


Features:
The sheath of the heater is rust resistance.
High class Nickel Chrome ribbon is used.
Maximum power: 3w/cm2(s.steel),4.5w/cm2(brass),6.5w/cm2(ceramic insulation)
Operating temperature up maximum of 500 degree centigrade
Axial, Radial & Tangential terminals are available
Thermocouple holes can be provided as per client's requirements
All Displayed Only for Retail Price, Bulk Purchase Welcome to Contact us for Detail



Specification:

Product Name	Band Heater
Voltage	220V
Power	150W
Band Size	50×30mm(Inside Dia.*H)
Main Materials	Stainless Steel
Withstand Temperature	300°C-400°C
Weight	75g/pc
Package	2pcs Band Heater

Note:
If you need 110V or 380V, please remark in the order. If without any remark, the shipment will be arranged as 220V.




Custom:
The band heater can be customized according to your request. But please offer your request, including:
Voltage/Power/Band Sizes(D/H)
Besides, There are some sizes for your choices, please click the size for your needed.

Size (Inside Dia.*H)	Voltage	Power	Size (Inside Dia.*H)	Voltage	Power
25×25mm	220V	60W	50×45mm	220V	220W
25×30mm	220V	70W	50×50mm	220V	240W
30×25mm	220V	70W	50×60mm	220V	290W
30×30mm	220V	90W	50×65mm	220V	310W
30×35mm	220V	100W	55×35mm	220V	190W
30×40mm	220V	120W	55×40mm	220V	210W
30×45mm	220V	130W	55×45mm	220V	240W
30×50mm	220V	150W	55×50mm	220V	260W
35×25mm	220V	90W	55×60mm	220V	310W
35×30mm	220V	100W	60×25mm	220V	150W
35×35mm	220V	120W	60×30mm	220V	170W
35×40mm	220V	140W	60×35mm	220V	200W
35×50mm	220V	170W	60×40mm	220V	230W
35×60mm	220V	200W	60×45mm	220V	260W
40×30mm	220V	120W	60×50mm	220V	290W
40×35mm	220V	110W	60×55mm	220V	310W
40×40mm	220V	150W	60×60mm	220V	340W
40×45mm	220V	140W	60×65mm	220V	370W
40×50mm	220V	190W	65×50mm	220V	310W
40×55mm	220V	210W	65×55mm	220V	340W
45×30mm	220V	130W	65×60mm	220V	370W
45×35mm	220V	150W	70×40mm	220V	270W
45×40mm	220V	170W	70×50mm	220V	330W
45×45mm	220V	200W	70×60mm	220V	400W
45×50mm	220V	220W	80×50mm	220V	380W
50×30mm	220V	150W	85×40mm	220V	320W
50×35mm	220V	170W	90×90mm	220V	770W
50×40mm	220V	190W	100×100mm	220V	950W

FAQ

1). Q: Can you give me a discount price?
A: It is depending on the volume. The larger the volume is, the more discount you can enjoy.
(2). Q: Why is your price a bit higher than other Chinese suppliers?
A: To meet the requirement of different customers and areas, our factory manufactures various kinds of quality for each item at a wide range of price. We can offer the products of different quality levels depending on customer's target price and quality requirement.
(3). Q: How can I get a sample?
A: Normally small samples can be sent free of charge and customers just need to bear a little shipping charge, or you can provide your DHL,FEDEX,EMS,UPS courier account number to us. For bigger sizes, it depends.
(4). Q: How can you guarantee the quality of mass production is same with the sample sent to me before?
A: Our warehouse staff will leave another same sample in our company, with your company name marked on it, which our production will be based on.
(5). Q: How can you deal with quality issues that customer feedback after receiving the goods?
1) Customers take photos of unqualified goods and then our sales staff will send them to Engineering Department to verify.
2) If the issue is confirmed, our sales staff will explain the root cause and take corrective actions in coming orders.
3) Finally, we will negotiate with our customers to make some compensation.
