GUANGDONG GUANGYUN NEW MATERIAL CO., LTD. >> EPA Heat Dissipation Aluminum Base Copper Clad Laminated

EPA Heat Dissipation Aluminum Base Copper Clad Laminated

EPA Heat Dissipation Aluminum Base Copper Clad Laminated
Price: NegotiablePIECES
Min Order: 1000PIECES
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: EPA-M1
Aluminium Alloy: 1060 1100 3003 5052 6061
Aluminium Thickness: 0.4/0.6/0.8/1.0/1.2/1.5/2.0/3.0mm
Copper: 0.5oz 1oz 2oz
Insulation Thickness: 60-100micro Meter
Thermal Stress: 288 Celsius Degree>=2min
Peel Strength: 1.2n/mm
Hi-Pot Voltage: 1.5kv(DC)
Break-Down Voltage: 3.0kv(AC)
CTI: Grade 3
Tg (DSC): >135 Celsius Degree
Type: Flexible Circuit Board
Flame Retardant Properties: V0
Dielectric: Copper Foil
Insulation Materials: Ceramic Based Polymeric Materials
Application: Printed Circut Board
Material: Aluminium Base Copper Clad
Brand: Guiyu

Product Description

EPA Heat Dissipation Aluminium Base Copper Clad Laminated
application: LED lighting,stage/stree light LED light/lamp
sizes:500x600mm  600x1000mm,500x1200mm, 1000x1200mm
1.0W,1.5W,2.0W,3.0W,4.0W





Located in Yunfu High-tech Development Zone, Guangdong Guangyun New Material Co., Ltd is a large private enterprise. It mainly processing and selling galvanized steel and aluminum sheet strip and foil and so on metal materials and occupies quite big market share and high reputation in the same industry, even in the South of China.

It has advanced equipments and production line, including 6 new production lines (FATA) of continuous casting machine, 2 cold rolling lines, tension leveled line, cutting and slitting, aluminum foil slitter and all other imported equipments along with the international competitive modernized aluminum processing lines. Therefore, it can flexibly supply and process galvanized steel and aluminum foil products with different kinds of models and annual capacity reach about 300, 000.00 metric tons. Its products including galvanized steel, aluminum sheet, aluminum sheet for curtain panel, aluminum coil, aluminum foil, aluminum sheets for PCB, aluminum sheets for bottle caps, aluminum circle, aluminum tread plate, aluminum embossed sheet and coil, imported aluminum sheet, aluminum corrugated sheet for roofing, aluminum coating sheet and coil and so on are favored among customers from different countries all over the world...

With well-funded financial background, Guangdong Guangyun New Material Co., Ltd have built friendly relations and cooperation with dozens of large steel plate and aluminum processing enterprises from home and abroad for a long term. Complete models and high quality make its goal-powerful alliances to achieve a win-win situation -comes true.

In the future, we will firmly adhere to our principle of "Establish Company Image by Creating Our Own Brand, Strive To be The Best by Providing High Quality Service", and it is our sincerest wish to hand in hand and create brilliance with you!
